S3 50W LED Floodlight 120lm/W IP65

Technical Specifications

• Electrical Features

  • Electrical Insulation ClassI
  • Frequency50-60 Hz
  • Light SourceSANAN SMD2835
  • Minimum and maximum voltage fluctuation that the product can withstand momentarily.
    Nominal Voltage198 V - 240 V
  • Remote ControlNo
  • Voltage level required for the product to function correctly.
    Voltage Range220-240V AC
  • Wattage50 W

• Mechanical Features

  • Temperature range in which the product can operate optimally, ensuring its performance without overheating or damage.
    Ambient Working Temperature-20 °C~+50 °C
  • Indicates whether the product or its materials are fire-resistant, enhancing safety in high-temperature or flame-risk areas.
    Fire RatedNo
  • Protection grade that the product offers against physical impacts. It is measured on a scale from IK00 to IK10, with IK10 being the highest level of resistance to impact and mechanical damage.
    IK ProtectionIK05
  • InstallationSurface
  • Installation of the bracketWall with U-bracket, Pole with U-bracket, On-wall base with U-bracket
  • The IP protection indicates the level of resistance of a product to dust and water. The higher the number, the more protected it is.
    IP RatingIP65
  • LocationOutdoor
  • Special Installation EnvironmentHigh ambient temperature

• Product Information

  • CertificatesCE, RoHS, UKCA
  • Guarantee3 years
  • Product SeriesS-ECO

• LED Features

  • Measures in degrees how light spreads from the source. A wide angle covers more area, while a narrow one is ideal for highlighting details.
    Beam Angle120º
  • Measures how accurately a light source displays colours compared to natural light. A high CRI (close to 100) ensures accurate colour rendering.
    Colour Rendering Index80
  • Defines the light tone, from warm white to cool white, measured in Kelvin (K).
    Colour Temperature5000K
  • Estimated lifespan of the product before it loses performance. Based on optimal, non-continuous use, and measured in hours of operation under controlled conditions.
    Hours40.000 hours
  • Efficiency of the LEDs, measured as the amount of light generated per unit of energy consumed (lumens per watt). High efficiency ensures energy savings without losing light quality.
    LED Performance120 lm/W
  • Light ColourDaylight
  • Lumen5500 lm
  • Ratio between light output (lumens) and energy consumed (watts). A high value indicates better efficiency, ideal for saving energy without compromising lighting.
    Luminous Efficiency110 lm/W
  • Number of LEDs90
  • Power Factor0.9
  • Standard colour deviation (MacAdam)SDCM ≤ 6

• Materials and Finishes

  • ColourBlack
  • Fitting MaterialGlass, Aluminium

• Driver Information

  • WifiNo
