60W LED Streetlight LUMILEDS PHILIPS Xitanium Villa

Technical Specifications

• LED Features

  • Defines the light tone, from warm white to cool white, measured in Kelvin (K).
    Colour Temperature2200K
  • Estimated lifespan of the product before it loses performance. Based on optimal, non-continuous use, and measured in hours of operation under controlled conditions.
    Hours100.000 hours
  • Efficiency of the LEDs, measured as the amount of light generated per unit of energy consumed (lumens per watt). High efficiency ensures energy savings without losing light quality.
    LED Performance160 lm/W
  • Light ColourCandlelight
  • Lumen9000 lm
  • Ratio between light output (lumens) and energy consumed (watts). A high value indicates better efficiency, ideal for saving energy without compromising lighting.
    Luminous Efficiency150 lm/W
  • Number of LEDs24
  • Power Factor0.95
  • Percentage of light emitted upwards by the product when installed. A low ULOR reduces light pollution.
    UlorLess than 0.1%

• Mechanical Features

  • Temperature range in which the product can operate optimally, ensuring its performance without overheating or damage.
    Ambient Working Temperature-20 °C~+45 °C
  • Protection grade that the product offers against physical impacts. It is measured on a scale from IK00 to IK10, with IK10 being the highest level of resistance to impact and mechanical damage.
    IK ProtectionIK09
  • The IP protection indicates the level of resistance of a product to dust and water. The higher the number, the more protected it is.
    IP RatingIP66
  • LocationOutdoor
  • Type of lens that determines the distribution and quality of the light. It influences the illumination angle and light efficiency.
    OpticAsymmetrical 140ºx60º

• Electrical Features

  • Electrical Insulation ClassI
  • Frequency50-60 Hz
  • Light SourceLUMILEDS SMD5050
  • Minimum and maximum voltage fluctuation that the product can withstand momentarily.
    Nominal Voltage100 V - 240 V
  • Product's ability to withstand voltage spikes or electrical overloads, protecting internal components from potential damage due to current fluctuations.
    Overvoltage Protection6 kV
  • Voltage level required for the product to function correctly.
    Voltage Range220-240V AC
  • Wattage60 W

• Materials and Finishes

  • ColourBlack
  • Fitting MaterialAluminium, Glass

• Product Information

  • CertificatesCE, RoHS, ENEC
  • Guarantee5 years

• Driver Information

  • Driver BrandPHILIPS Xitanium
  • WifiNo
