Range Expert

Wattage 200 W
Voltage Range 220-240V AC
Lumen 40000 lm
Diameter 300 mm

1 / 4

Wattage
200 W
Voltage Range
220-240V AC
Lumen
40000 lm
Diameter
300 mm
Number of LEDs
600
Type Of Dimming
DALI, Push button
Power Factor
0.95
IP Rating
IP65
Battery Operated
No
Dimensions
148 mm x Ø300 mm
IK Protection
IK08
Luminous Efficiency
200 lm/W

New

£93.99

VAT included

In Stock, delivery in 16-21 days

Not Included Remote

Are you a lighting professional or a company?

Great discounts off PVP
Extended Warranty
Exclusive Services

Dimensions

Weight1.3 kg
Diameter300 mm

Downloads

PDF Datasheet 177557_359437 EN
DoC_177557_359437

Certificates and Stamps

Technical Specifications

Electrical Features
- Electrical Insulation ClassI
- Frequency50-60 Hz
- Light SourceLUMILEDS SMD2835
- Minimum and maximum voltage fluctuation that the product can withstand momentarily.
  Nominal Voltage120 V - 277 V
- Type Of DimmingDALI, Push button
- Voltage level required for the product to function correctly.
  Voltage Range220-240V AC
- Wattage200 W
Mechanical Features
- Temperature range in which the product can operate optimally, ensuring its performance without overheating or damage.
  Ambient Working Temperature-20 °C~+50 °C
- Protection grade that the product offers against physical impacts. It is measured on a scale from IK00 to IK10, with IK10 being the highest level of resistance to impact and mechanical damage.
  IK ProtectionIK08
- The IP protection indicates the level of resistance of a product to dust and water. The higher the number, the more protected it is.
  IP RatingIP65
- LocationOutdoor
- Type of lens that determines the distribution and quality of the light. It influences the illumination angle and light efficiency.
  Optic90º
- Internal temperature range in which the product can operate efficiently and safely. It is important to ensure its reliability under different usage conditions.
  Working Temperature-30 °C~+45 °C
Product Information
- CertificatesCE, RoHS, UKCA, ERP
- Guarantee7 years
- Product SeriesHBM
Materials and Finishes
- ColourBlack
- Fitting MaterialAluminium
- Not IncludedRemote
LED Features
- Measures how accurately a light source displays colours compared to natural light. A high CRI (close to 100) ensures accurate colour rendering.
  Colour Rendering Index80
- Defines the light tone, from warm white to cool white, measured in Kelvin (K).
  Colour Temperature4000K
- Estimated lifespan of the product before it loses performance. Based on optimal, non-continuous use, and measured in hours of operation under controlled conditions.
  Hours100.000 hours
- Light ColourCool White
- Lumen40000 lm
- Ratio between light output (lumens) and energy consumed (watts). A high value indicates better efficiency, ideal for saving energy without compromising lighting.
  Luminous Efficiency200 lm/W
- Number of LEDs600
- Power Factor0.95
- Standard colour deviation (MacAdam)SDCM ≤ 7
Driver Information
- Driver BrandSOSEN
- Driver Intensity700 mA - 1000 mA
- Driver Power200 W
- Voltage level that the driver uses to power the LEDs or electrical components of the product, ensuring their proper functioning.
  Driver Tension180 V-260 V
- Type Of DriverDALI
- WifiNo

Description

Industrial LED high bay designed for demanding environments, with high efficiency of 190 lm/W and LUMILEDS components and SOSEN driver, DALI/Push dimmable.

Design and style

Built in aluminium for reliable heat dissipation and stable operation in intensive use. Its UFO form factor facilitates integration in factories, warehouses and production areas, maintaining a technical and discreet presence. Intended to blend subtly into the environment and provide a functional, balanced solution for different spaces.

Use and application

Suitable for outdoor use with IP65 and IK08 protection, ideal for areas exposed to dust and water jets, as well as moderate mechanical impacts. Designed to provide comfortable lighting according to the environment and to facilitate appropriate illumination depending on the installation.

Key benefits

Luminous efficacy of 190 lm/W to optimise energy performance.
DALI/Push dimming for precise control according to process needs.
IP65 and IK08 protection rating for demanding industrial environments.
LUMILEDS SMD2835 light source and SOSEN driver focused on reliability.
Service life of 100,000 hours to reduce maintenance interventions.

Technical details

Class I. Frequency 50–60 Hz. Voltage 220–240 V AC. Power factor 0.95. CRI 70. Material: aluminium. LUMILEDS SMD2835 light source. IP65 and IK08 protection. Operating temperature -30 °C~+45 °C. Ambient operating temperature -20 °C~+50 °C. Service life 100,000 hours. Certifications: CE, ERP, RoHS, UKCA. HBM series.

Installation and maintenance

Supports DALI/Push dimming via SOSEN driver for integration into existing control systems. Installation by qualified personnel is recommended and watertightness should be checked to maintain IP65. Does not include sensor or emergency lighting.

For additional specifications on power, beam angle or mounting options, you can request more information.
