0
  • 240 W
    Wattage 240 W
  • 220-240V AC
    Voltage Range 220-240V AC
  • DALI 2
    Type Of Dimming DALI 2
  • 0.96
    Power Factor 0.96
Image of 220-240V INVERTRONICS DALI-2 Dimmable Driver 18-57V DC Output 4200-6700mA 240W IP67 EUM-240S670BG
  • 240 W

    Wattage

    240 W

  • 220-240V AC

    Voltage Range

    220-240V AC

  • DALI 2

    Type Of Dimming

    DALI 2

  • 0.96

    Power Factor

    0.96

  • IP67

    IP Rating

    IP67

  • No

    Battery Operated

    No

  • 39 mm x 60 mm x 201 mm

    Dimensions

    39 mm x 60 mm x 201 mm

  • 60 mm

    Width

    60 mm

  • 39 mm

    Height

    39 mm

  • Aluminium

    Fitting Material

    Aluminium

  • Yes

    Dimmable

    Yes

220-240V INVERTRONICS DALI-2 Dimmable Driver 18-57V DC Output 4200-6700mA 240W IP67 EUM-240S670BG

Download technical datasheet

Ref. Ledkia: 117668

EAN 13: 8445044199556

Colour Grey

£82.99

VAT included

In Stock, delivery in 24/48h

PRO CLUB badge

Are you a lighting professional or a company?

  • Great discounts off PVP
  • Extended Warranty
  • Exclusive Services

Buy now, pay later

Credit payment

    • 30 calendar days to return

      You can renounce to this product during the first 30 calendar days from receipt, provided that the product remains in perfect condition for use.


      Custom-made products and cut-to-size strips are excluded.


      Full conditions here: After-Sales Service.

    • 24h Delivery

      If you place your order today before 2:30 pm, delivery within 24/48h (working days).


      Shipping is free on purchases over £49.99 (incl. VAT).


      Full conditions here: Shipping methods.

    • 100% secure payments

      payment method image 1

      payment method image 2

      At Ledkia we strive to protect your security and privacy. We use payment methods that guarantee your security. Both your personal and bank details are protected with all the security measures established in the current legislation.


      More information: Payment methods.

    • Warranty up to 5 years

      Our warranty service of up to 5 years guarantees the replacement, repair or refund of defective products.


      You will find the exact product warranty in the technical details.


      Full conditions here: After-Sales Service.

Dimensions

  • Depth201 mm
  • Height39 mm
  • Width60 mm

Downloads

  • pdf file

    Technical Data Sheet PDF

  • pdf file

    DoC_117668_246876

Certificates and Stamps

CertificateCertificateCertificateCertificateCertificate

Technical Specifications

  • Electrical Features

    • Electrical Insulation ClassI
    • Frequency50-60 Hz
    • Product's ability to withstand voltage spikes or electrical overloads, protecting internal components from potential damage due to current fluctuations.
      Overvoltage Protection10 kV
    • Type Of DimmingDALI 2
    • Voltage level required for the product to function correctly.
      Voltage Range220-240V AC
    • Wattage240 W

  • LED Features

    • Power Factor0.96

  • Mechanical Features

    • Temperature range in which the product can operate optimally, ensuring its performance without overheating or damage.
      Ambient Working Temperature-20 °C~+50 °C
    • The IP protection indicates the level of resistance of a product to dust and water. The higher the number, the more protected it is.
      IP RatingIP67
    • LocationOutdoor, Indoor

  • Product Information

    • CertificatesCE, RoHS, CCC, ENEC, UKCA
    • Guarantee3 years

  • Materials and Finishes

    • ColourGrey
    • Fitting MaterialAluminium

  • Driver Information

    • Driver BrandINVENTRONICS
    • Driver Intensity4200 mA-6700 mA
    • Voltage level that the driver uses to power the LEDs or electrical components of the product, ensuring their proper functioning.
      Driver Tension18 V-57 V
    • WifiNo

Description

Driver from the prestigious company INVENTRONICS specifically designed for LED street lighting. A LED driver is responsible for converting the alternating current from the electrical grid into direct current suitable for illuminating LED chips. To know if a driver will work with our luminaire, PCB or panel, we should check the output voltage and current of the driver.

Features of the 220-240V INVERTRONICS DALI-2 Dimmable Driver 18-57V DC Output 4200-6700mA 240W IP67 EUM-240S670BG

This driver has multi-voltage input. This means it can withstand voltage fluctuations during a short period without suffering damage. Additionally, its output is also multi-voltage, meaning it can deliver a constant voltage within a range, allowing the same driver to be used for various applications with different current and voltage requirements.

Once the driver is powered, the voltage will automatically adjust, and the output voltage will be constant. The DALI-2 dimmable driver must be used with a compatible dimmer, which will allow us to easily select the desired light intensity. Its power factor is very high, making it a very efficient driver.

The high efficiency of this driver and its compact metal casing allow it to operate in cooler temperatures, significantly improving reliability and extending its lifespan.

This driver, in addition to having DALI-2 dimming, can also be dimmed via 1-5V, 10V PWM modulation. On the other hand, it has 3 types of dimming:

- Nighttime Self-Adaptation: automatically adjusts the dimming curve based on the on-time of the last two days, with the midpoint of the dimming curve being midnight.

- Self-Adaptation Percentage: automatically adjusts the on-time at each step by a constant percentage.

- Additional Timer: follows the programmed timing curve after being turned on without changes.
