Wattage 600 W
Voltage Range 220-240V AC
Lumen 90000 lm
Type Of Dimming 1-10 V
Wattage
600 W
Voltage Range
220-240V AC
Lumen
90000 lm
Type Of Dimming
1-10 V
Power Factor
0.95
IP Rating
IP66
Battery Operated
No
Dimensions
137 mm x 510 mm x 564 mm
Width
510 mm
Height
137 mm
IK Protection
IK08
Luminous Efficiency
150 lm/W
Professional Stadium 600W 1-10V Dimmable LED Floodlight INVENTRONICS 170lm/W IP66 LUMILEDS
Ref. Ledkia: 115721
Colour Temperature Daylight 5000K
Optic 60º
In Stock, delivery in 16-21 days
£630.99
VAT included
In Stock, delivery in 16-21 days
Are you a lighting professional or a company?
- Great discounts off PVP
- Extended Warranty
- Exclusive Services
Buy now, pay later
Credit payment30 calendar days to return
You can renounce to this product during the first 30 calendar days from receipt, provided that the product remains in perfect condition for use.
Custom-made products and cut-to-size strips are excluded.
Full conditions here: After-Sales Service.
24h Delivery
If you place your order today before 2:30 pm, delivery within 24/48h (working days).
Shipping is free on purchases over £49.99 (incl. VAT).
Full conditions here: Shipping methods.
100% secure payments
At Ledkia we strive to protect your security and privacy. We use payment methods that guarantee your security. Both your personal and bank details are protected with all the security measures established in the current legislation.
More information: Payment methods.
Warranty up to 5 years
Our warranty service of up to 5 years guarantees the replacement, repair or refund of defective products.
You will find the exact product warranty in the technical details.
Full conditions here: After-Sales Service.
Dimensions
- Dimensions137 mm x 510 mm x 564 mm
- Cable Length150 cm
- Weight18.8 kg
Downloads
PDF Datasheet 115721_236512 EN
Installation Manual
DoC_115721_236512
Certificates and Stamps
Technical Specifications
Electrical Features
- DimmableYes
- Electrical Insulation ClassI
- Frequency50-60 Hz
- Light SourceLUMILEDS 3030
- Nominal Voltage100 V - 277 VMinimum and maximum voltage fluctuation that the product can withstand momentarily.
- Overvoltage Protection10 kVProduct's ability to withstand voltage spikes or electrical overloads, protecting internal components from potential damage due to current fluctuations.
- Type Of Dimming1-10 V
- Voltage Range220-240V ACVoltage level required for the product to function correctly.
- Wattage600 W
Mechanical Features
- Ambient Working Temperature-20 °C~+40 °CTemperature range in which the product can operate optimally, ensuring its performance without overheating or damage.
- IK ProtectionIK08Protection grade that the product offers against physical impacts. It is measured on a scale from IK00 to IK10, with IK10 being the highest level of resistance to impact and mechanical damage.
- InstallationSurface
- Installation of the bracketWall with U-bracket, On-wall base with U-bracket, Pole with U-bracket
- IP RatingIP66The IP protection indicates the level of resistance of a product to dust and water. The higher the number, the more protected it is.
- LocationOutdoor, Indoor
- Modular Product (Requires Assembly)No
- Optic60ºType of lens that determines the distribution and quality of the light. It influences the illumination angle and light efficiency.
Product Information
- CertificatesCE, RoHS, UKCA
- Guarantee7 years
- Product SeriesStadium PRO-I
LED Features
- Colour Rendering Index80Measures how accurately a light source displays colours compared to natural light. A high CRI (close to 100) ensures accurate colour rendering.
- Colour Temperature5000KDefines the light tone, from warm white to cool white, measured in Kelvin (K).
- Hours80.000 HorasEstimated lifespan of the product before it loses performance. Based on optimal, non-continuous use, and measured in hours of operation under controlled conditions.
- LED Performance170 lm/WEfficiency of the LEDs, measured as the amount of light generated per unit of energy consumed (lumens per watt). High efficiency ensures energy savings without losing light quality.
- Light ColourDaylight
- Lumen90000 lm
- Luminous Efficiency150 lm/WRatio between light output (lumens) and energy consumed (watts). A high value indicates better efficiency, ideal for saving energy without compromising lighting.
- Power Factor0.95
- Standard colour deviation (MacAdam)SDCM ≤ 5
Materials and Finishes
- ColourBlack
- Fitting MaterialSteel, Aluminium, Glass, PC
Driver Information
- Driver BrandINVENTRONICS
- Driver Intensity7600 mA
- Driver Power456 W
- Driver Tension21 V-60 VVoltage level that the driver uses to power the LEDs or electrical components of the product, ensuring their proper functioning.
- WifiNo
Description
The Professional Stadium 600W LED Floodlight offers 1-10V dimming and a luminous efficiency of 150 lm/W, designed for demanding indoor and outdoor applications with an IP66 protection rating and IK08 impact resistance.
General information about Professional Stadium 600W 1-10V Dimmable LED Floodlight INVENTRONICS 170lm/W IP66 LUMILEDS
This product belongs to the Stadium Profesional series, a range of LED floodlights specialised for professional sports lighting. It features a robust construction with a combination of steel, aluminium, glass and polycarbonate materials. Equipped with LUMILEDS 3030 light sources and an INVENTRONICS driver, it provides a luminous flux of 90,000 lumens and a power factor of 0.95. The floodlight supports 1-10 V dimming and includes overvoltage protection up to 10 kV. Its dimensions are 137 mm x 510 mm x 564 mm, suitable for surface mounting.
Use and applications
This LED floodlight is indicated for both indoor and outdoor environments, ideal for illuminating access points, façades, gardens, yards, perimeters, and internal roads. It is oriented towards sectors such as public administration, construction and building sites, industry and production, and logistics and warehouses. Its adaptability and high luminous output make it suitable for large-scale professional lighting projects.
Key benefits
- High luminous efficiency of 150 lm/W ensures effective lighting performance with precise light output.
- 1-10 V dimming allows adjustable light levels for tailored illumination control.
- IP66 protection rating guarantees resistance against dust and powerful water jets, suitable for outdoor use.
- IK08 impact resistance provides protection against mechanical impacts in demanding environments.
- Overvoltage protection up to 10 kV safeguards the floodlight from electrical surges.
Highlighted specifications
Wattage: 600 W; Colour Rendering Index (CRI): 80; Operating temperature: -20 °C to +40 °C.
Installation and maintenance
The floodlight is designed for surface mounting and can be installed using a wall, pole or on-wall base with U-bracket. Installation must follow the indicated mounting system, ensuring secure fixing and correct orientation. Disconnect the power supply before any intervention to guarantee safety during installation and maintenance procedures.
Frequently asked questions
- What type of dimming does this floodlight support? — It supports 1-10 V dimming for adjustable light output.
- What is the IP rating of this product? — The floodlight has an IP66 rating for dust and water resistance.
- Which driver brand is used? — It includes an INVENTRONICS driver.
- Is overvoltage protection included? — Yes, protection up to 10 kV is integrated.
- What is the recommended installation method? — Surface mounting with options for wall, pole or on-wall base with U-bracket.
Specialised distribution of technical lighting in the United Kingdom. If you are looking to buy Professional Stadium 600W 1-10V Dimmable LED Floodlight INVENTRONICS 170lm/W IP66 LUMILEDS for a technical or professional project, the Stadium Profesional series identifies the range to which this reference belongs. Shipping estimated in 15 to 20 days (subject to stock availability). CE, RoHS and UKCA certifications apply. Check price and availability.
This product requires assembly by the customer. For correct handling and installation, please refer to the installation manual.
