Wattage 800 W
Voltage Range 220-240V AC
Lumen 120000 lm
Type Of Dimming 0-10 V
Wattage
800 W
Voltage Range
220-240V AC
Lumen
120000 lm
Type Of Dimming
0-10 V
Power Factor
0.98
IP Rating
IP66
Battery Operated
No
Dimensions
600 mm x 188 mm x 353 mm
Width
188 mm
Height
600 mm
IK Protection
IK08
Luminous Efficiency
150 lm/W
Stadium 800W 0-10V Dimmable LIFUD LED Floodlight 160lm/W IP66
Ref. Ledkia: 110486
Colour Temperature Daylight 5000K
Optic 60º
In Stock, delivery in 16-21 days
Premium range
£856.99Before £625.99
£572.99
VAT included
In Stock, delivery in 16-21 days
Modular Product (Requires Assembly)
Are you a lighting professional or a company?
- Great discounts off PVP
- Extended Warranty
- Exclusive Services
Buy now, pay later
Credit payment30 calendar days to return
You can renounce to this product during the first 30 calendar days from receipt, provided that the product remains in perfect condition for use.
Custom-made products and cut-to-size strips are excluded.
Full conditions here: After-Sales Service.
24h Delivery
If you place your order today before 2:30 pm, delivery within 24/48h (working days).
Shipping is free on purchases over £49.99 (incl. VAT).
Full conditions here: Shipping methods.
100% secure payments
At Ledkia we strive to protect your security and privacy. We use payment methods that guarantee your security. Both your personal and bank details are protected with all the security measures established in the current legislation.
More information: Payment methods.
Warranty up to 5 years
Our warranty service of up to 5 years guarantees the replacement, repair or refund of defective products.
You will find the exact product warranty in the technical details.
Full conditions here: After-Sales Service.
Dimensions
- Weight10.75 kg
- Cable Length60 mm
- Dimensions600 mm x 188 mm x 353 mm
Downloads
PDF Datasheet 110486_225255 EN
Stadium LIFUD Installation Manual
DoC_110486_225255
Certificates and Stamps
Technical Specifications
LED Features
- Colour Rendering Index70Measures how accurately a light source displays colours compared to natural light. A high CRI (close to 100) ensures accurate colour rendering.
- Colour Temperature5000KDefines the light tone, from warm white to cool white, measured in Kelvin (K).
- Hours60.000 hoursEstimated lifespan of the product before it loses performance. Based on optimal, non-continuous use, and measured in hours of operation under controlled conditions.
- LED Performance160 lm/WEfficiency of the LEDs, measured as the amount of light generated per unit of energy consumed (lumens per watt). High efficiency ensures energy savings without losing light quality.
- Light ColourDaylight
- Lumen120000 lm
- Luminous Efficiency150 lm/WRatio between light output (lumens) and energy consumed (watts). A high value indicates better efficiency, ideal for saving energy without compromising lighting.
- Number of switch-on cycles25000
- Power Factor0.98
- Standard colour deviation (MacAdam)SDCM ≤ 5
Electrical Features
- DimmableYes
- Electrical Insulation ClassI
- Frequency50-60 Hz
- Light SourceSMD5050
- Overvoltage Protection6 kVProduct's ability to withstand voltage spikes or electrical overloads, protecting internal components from potential damage due to current fluctuations.
- Type Of Dimming0-10 V
- Voltage Range220-240V ACVoltage level required for the product to function correctly.
- Wattage800 W
Mechanical Features
- Ambient Working Temperature-20 °C~+50 °CTemperature range in which the product can operate optimally, ensuring its performance without overheating or damage.
- IK ProtectionIK08Protection grade that the product offers against physical impacts. It is measured on a scale from IK00 to IK10, with IK10 being the highest level of resistance to impact and mechanical damage.
- InstallationSurface
- Installation of the bracketWall with U-bracket, On-wall base with U-bracket, Ceiling with U-bracket
- IP RatingIP66The IP protection indicates the level of resistance of a product to dust and water. The higher the number, the more protected it is.
- LocationOutdoor, Indoor
- Modular Product (Requires Assembly)Yes
- Optic60ºType of lens that determines the distribution and quality of the light. It influences the illumination angle and light efficiency.
- Special Installation EnvironmentHigh ambient temperature
- Working Temperature-20 °C~+45 °CInternal temperature range in which the product can operate efficiently and safely. It is important to ensure its reliability under different usage conditions.
Product Information
- CertificatesCE, RoHS, UKCA
- Guarantee3 years
- Product SeriesStadium PRO-I
Materials and Finishes
- ColourBlack
- Fitting MaterialPC, Aluminium
Driver Information
- Driver BrandLIFUD
- Driver Intensity0.9 A
- Driver Power180 W
- Driver Tension90 V - 305 VVoltage level that the driver uses to power the LEDs or electrical components of the product, ensuring their proper functioning.
- WifiNo
Description
The Stadium 800W 0-10V Dimmable LIFUD LED Floodlight offers high-power illumination with IP66 protection rating and IK08 impact resistance, suitable for demanding environments requiring robust lighting solutions.
General information about Stadium 800W 0-10V Dimmable LIFUD LED Floodlight 160lm/W IP66
This product belongs to the Stadium Profesional series, a range of LED floodlights designed for professional sports lighting with a modular design. It features a 0-10 V dimming system and is equipped with a LIFUD driver operating at 90 V - 305 V and 0.9 A intensity. The floodlight provides a luminous efficiency of 150 lm/W with a total luminous flux of 120,000 lumens, powered at 800 W. Constructed with aluminium and polycarbonate materials, it has an electrical insulation class I and overvoltage protection up to 6 kV.
Use and applications
The floodlight is designed for both indoor and outdoor use, suitable for industrial and production environments. It is ideal for illuminating access points, façades, and perimeter walls or fencing, providing reliable lighting for areas requiring high-intensity coverage. Its robust surface mounting options include installation with a U-bracket on walls, ceilings, or on-wall bases, making it adaptable to various architectural and technical requirements.
Key benefits
- High luminous efficiency ensures powerful lighting output with 150 lm/W, supporting bright and effective illumination.
- 0-10 V dimming control allows precise adjustment of light levels to match specific needs and energy management.
- IP66 protection rating provides resistance against dust and water ingress, suitable for harsh outdoor conditions.
- IK08 impact resistance safeguards the fixture against mechanical impacts, enhancing durability in industrial settings.
- Overvoltage protection up to 6 kV protects the floodlight from electrical surges, increasing operational safety.
Highlighted specifications
Power: 800 W; Dimensions: 600 mm x 188 mm x 353 mm; Colour Rendering Index (CRI): 70; Ambient working temperature: -20 °C to +50 °C.
Installation and maintenance
Installation is performed via surface mounting using the included U-bracket system, which supports wall, ceiling, and on-wall base configurations. The product is modular and requires assembly by the customer. Disconnect power supply before any installation or maintenance task. Refer to the installation manual for detailed instructions to ensure correct handling and secure mounting.
Frequently asked questions
- What type of dimming does this floodlight use? — It uses a 0-10 V dimming system for light level adjustment.
- Which driver brand is installed in this product? — The floodlight is equipped with a LIFUD driver.
- Is this floodlight suitable for outdoor use? — Yes, it has an IP66 rating making it suitable for outdoor environments.
- What is the impact resistance rating? — The product has an IK08 impact protection level.
- Does the product include overvoltage protection? — Yes, it includes protection up to 6 kV.
Specialised distribution of technical lighting in the United Kingdom. If you are looking to buy Stadium 800W 0-10V Dimmable LIFUD LED Floodlight 160lm/W IP66 for a technical or professional project, the Stadium Profesional series identifies the range to which this reference belongs. Shipping estimated in 15 to 20 days (subject to stock availability). CE, RoHS, UKCA certified. Check price and availability.
This product requires assembly by the customer. For correct handling and installation, please refer to the installation manual.
