Range Essential
  • 220-240V AC
    Voltage Range 220-240V AC
  • 300 W
    Max Wattage 300 W
  • IP65
    IP Rating IP65
  • 62 mm x 80 mm x 103 mm
    Dimensions 62 mm x 80 mm x 103 mm
Image of Adjustable PIR Motion Sensor 360º IP65
    Image of Adjustable PIR Motion Sensor 360º IP65
    Image of Adjustable PIR Motion Sensor 360º IP65
    Image of Adjustable PIR Motion Sensor 360º IP65
    Image of Adjustable PIR Motion Sensor 360º IP65
    Image of Adjustable PIR Motion Sensor 360º IP65
    Image of Adjustable PIR Motion Sensor 360º IP65
    Image of Adjustable PIR Motion Sensor 360º IP65
    Image of Adjustable PIR Motion Sensor 360º IP65
    Image of Adjustable PIR Motion Sensor 360º IP65
    Image of Adjustable PIR Motion Sensor 360º IP65
1 / 10
  • 220-240V AC

    Voltage Range

    220-240V AC

  • 300 W

    Max Wattage

    300 W

  • IP65

    IP Rating

    IP65

  • 62 mm x 80 mm x 103 mm

    Dimensions

    62 mm x 80 mm x 103 mm

  • 80 mm

    Width

    80 mm

  • 62 mm

    Height

    62 mm

  • PC

    Fitting Material

    PC

Adjustable PIR Motion Sensor 360º IP65

Download technical datasheet

Ref. Ledkia: 100258

Colour White

£13.29

VAT included

In Stock, delivery in 15-20 days

Includes Screws

PRO CLUB badge

Are you a lighting professional or a company?

  • Great discounts off PVP
  • Extended Warranty
  • Exclusive Services

Buy now, pay later

Credit payment

    • 30 calendar days to return

      You can renounce to this product during the first 30 calendar days from receipt, provided that the product remains in perfect condition for use.


      Custom-made products and cut-to-size strips are excluded.


      Full conditions here: After-Sales Service.

    • 24h Delivery

      If you place your order today before 2:30 pm, delivery within 24/48h (working days).


      Shipping is free on purchases over £49.99 (incl. VAT).


      Full conditions here: Shipping methods.

    • 100% secure payments

      payment method image 1

      payment method image 2

      At Ledkia we strive to protect your security and privacy. We use payment methods that guarantee your security. Both your personal and bank details are protected with all the security measures established in the current legislation.


      More information: Payment methods.

    • Warranty up to 5 years

      Our warranty service of up to 5 years guarantees the replacement, repair or refund of defective products.


      You will find the exact product warranty in the technical details.


      Full conditions here: After-Sales Service.

Dimensions

  • Depth103 mm
  • Height62 mm
  • Width80 mm

Downloads

  • pdf file

    Technical Data Sheet PDF

  • pdf file

    DoC_100258_206802

Certificates and Stamps

CertificateCertificateCertificate

Technical Specifications

  • Mechanical Features

    • Temperature range in which the product can operate optimally, ensuring its performance without overheating or damage.
      Ambient Working Temperature-20 °C~+50 °C
    • Detection distance range16 m
    • Defines the sensitivity area of a sensor in degrees. A wider angle will detect motion over a larger area.
      Detection Range180 °
    • InstallationSurface
    • The IP protection indicates the level of resistance of a product to dust and water. The higher the number, the more protected it is.
      IP RatingIP65
    • SensorPIR
    • Sensor TypePIR

  • Electrical Features

    • Frequency50-60 Hz
    • Max Wattage300 W
    • Sensitivity10 Lux~2000 Lux
    • Voltage level required for the product to function correctly.
      Voltage Range220-240V AC

  • Product Information

    • CertificatesCE, RoHS, UKCA
    • Guarantee3 years

  • Materials and Finishes

    • ColourWhite
    • Fitting MaterialPC
    • IncludesScrews

Description

The 360° Adjustable PIR Motion Sensor IP65 is a waterproof and dustproof electronic device designed for use in outdoor areas such as gardens, driveways, patios and building entrances. With a detection range of 180° and 360° and a maximum detection distance of 12 meters (＜24℃）, this sensor is capable of detecting the presence of people or objects over a wide detection range. The time delay is adjustable from 10 seconds ±3 seconds to 15 minutes ±2 minutes.

The power supply is 220-240V AC 50/60Hz, and the maximum rated load is 1200W (incandescent lamp) or 300W (energy saving lamp/LED lamp). In addition, the sensor has an ambient light adjustment capability of <10 lux to 2000 lux. In summary, the IP65 adjustable 360° PIR motion sensor is highly effective in large areas and can be adjusted to suit different lighting conditions and time delay needs.
