Voltage Range 220-240V AC
Max Wattage 300 W
IP Rating IP44
Dimensions 65 mm x 95 mm x 98 mm
Voltage Range
220-240V AC
Max Wattage
300 W
IP Rating
IP44
Dimensions
65 mm x 95 mm x 98 mm
Width
95 mm
Height
65 mm
Fitting Material
PC
Design PIR Motion Sensor 180º
Ref. Ledkia: 100212
Colour White
£9.29
VAT includedIn Stock, delivery in 15-20 days
Are you a lighting professional or a company?
- Great discounts off PVP
- Extended Warranty
- Exclusive Services
Buy now, pay later
Credit payment30 calendar days to return
You can renounce to this product during the first 30 calendar days from receipt, provided that the product remains in perfect condition for use.
Custom-made products and cut-to-size strips are excluded.
Full conditions here: After-Sales Service.
24h Delivery
If you place your order today before 2:30 pm, delivery within 24/48h (working days).
Shipping is free on purchases over £49.99 (incl. VAT).
Full conditions here: Shipping methods.
100% secure payments
At Ledkia we strive to protect your security and privacy. We use payment methods that guarantee your security. Both your personal and bank details are protected with all the security measures established in the current legislation.
More information: Payment methods.
Warranty up to 5 years
Our warranty service of up to 5 years guarantees the replacement, repair or refund of defective products.
You will find the exact product warranty in the technical details.
Full conditions here: After-Sales Service.
Dimensions
- Weight110 kg
- Height65 mm
- Width95 mm
- Depth98 mm
Downloads
Technical Data Sheet PDF
DoC_100212_206765
Certificates and Stamps
Technical Specifications
Mechanical Features
- Ambient Working Temperature-20 °C~+50 °CTemperature range in which the product can operate optimally, ensuring its performance without overheating or damage.
- Detection distance range12 m
- Detection Range180 °Defines the sensitivity area of a sensor in degrees. A wider angle will detect motion over a larger area.
- InstallationSurface
- IP RatingIP44The IP protection indicates the level of resistance of a product to dust and water. The higher the number, the more protected it is.
- SensorPIR
- Sensor TypePIR
Electrical Features
- Frequency50-60 Hz
- Max Wattage300 W
- Sensitivity10 Lux~2000 Lux
- Voltage Range220-240V ACVoltage level required for the product to function correctly.
Product Information
- CertificatesCE, RoHS, UKCA
- Guarantee3 years
Materials and Finishes
- ColourWhite
- Fitting MaterialPC
Description
The 180º Design PIR Motion Sensor is an ideal motion detection solution for a wide variety of lighting applications. With a detection angle of 180 degrees , it can cover a wide and accurate detection area, up to 12 meters away in temperature conditions below 24°C .
The sensor has an adjustable time delay ranging from 10 seconds to 7 minutes , allowing the sensor run time to be customized to the user's needs. The 180º Design PIR Motion Sensor is powered by a 220-240V/AC 50/60Hz power supply and has a maximum nominal load of 1200W for incandescent lamps and 300W for low consumption or LED lamps.
The 180º Design PIR Motion Sensor also features an adjustable ambient light controller that can be set between 10 and 2000 LUX, making it suitable for use in a wide variety of environments with varying light levels. With an IP44 protection rating, the sensor is also resistant to moisture and dust ingress.
