Voltage Range 220-240V AC
Max Wattage 200 W
IP Rating IP20
Fitting Material PC
Voltage Range
220-240V AC
Max Wattage
200 W
IP Rating
IP20
Fitting Material
PC
Square Wall Mechanism Pro PIR Motion Sensor 120º
Ref. Ledkia: 100147
Colour White
£14.49
VAT includedIn Stock, delivery in 15-20 days
Are you a lighting professional or a company?
- Great discounts off PVP
- Extended Warranty
- Exclusive Services
Buy now, pay later
Credit payment30 calendar days to return
You can renounce to this product during the first 30 calendar days from receipt, provided that the product remains in perfect condition for use.
Custom-made products and cut-to-size strips are excluded.
Full conditions here: After-Sales Service.
24h Delivery
If you place your order today before 2:30 pm, delivery within 24/48h (working days).
Shipping is free on purchases over £49.99 (incl. VAT).
Full conditions here: Shipping methods.
100% secure payments
At Ledkia we strive to protect your security and privacy. We use payment methods that guarantee your security. Both your personal and bank details are protected with all the security measures established in the current legislation.
More information: Payment methods.
Warranty up to 5 years
Our warranty service of up to 5 years guarantees the replacement, repair or refund of defective products.
You will find the exact product warranty in the technical details.
Full conditions here: After-Sales Service.
Downloads
Technical Data Sheet PDF
DoC_100147_206683
Certificates and Stamps
Technical Specifications
Mechanical Features
- Ambient Working Temperature-20 °C~+50 °CTemperature range in which the product can operate optimally, ensuring its performance without overheating or damage.
- Detection distance range10 m
- Detection Range120 °Defines the sensitivity area of a sensor in degrees. A wider angle will detect motion over a larger area.
- InstallationRecessed
- IP RatingIP20The IP protection indicates the level of resistance of a product to dust and water. The higher the number, the more protected it is.
- SensorPIR
- Sensor TypePIR
Electrical Features
- Frequency50-60 Hz
- Max Wattage200 W
- Sensitivity10 Lux~2000 Lux
- Voltage Range220-240V ACVoltage level required for the product to function correctly.
Product Information
- CertificatesCE, RoHS, UKCA
- Guarantee3 years
Materials and Finishes
- ColourWhite
- Fitting MaterialPC
Description
This PIR motion sensor has a square design and is designed for wall mounting . It has a wide detection range of 120º , which allows it to cover a large area.
The sensor can detect motion at a maximum distance of 10 meters in ambient temperature conditions below 24℃. The delay time can be adjusted from 10 seconds to 7 minutes to customize how long the light stays on after motion is detected.
This motion sensor is powered by a 220-240V AC 50-60Hz power supply and has a maximum load rating of 500W for incandescent lamps, or 200W for LED/energy saving lamps. It also has an ambient light setting, allowing you to customize the sensitivity of the sensor to the light in your environment.
The recommended installation height for this motion sensor is 1 to 1.8 meters . It has an IP20 rating, which means it is protected against solid objects larger than 12.5mm , but it is not protected against the ingress of liquids. Therefore, it is recommended for indoor use. This motion sensor is ideal for commercial and residential use.
