IP Rating IP68
Width 152 mm
Height 152 mm
Current Intensity 16 A
IP Rating
IP68
Width
152 mm
Height
152 mm
Current Intensity
16 A
Working Temperature
-40 °C~+105 °C
Watertight 3-Contact Type X Cable with Quick Connector 0.5mm²-2.5mm² IP68
Ref. Ledkia: 92470
Colour Black
Before £9.99
£8.99
VAT includedPre-Order, estimated shipping from 28/05/2025
Are you a lighting professional or a company?
- Great discounts off PVP
- Extended Warranty
- Exclusive Services
Buy now, pay later
Credit payment30 Day Returns
You can renounce to this product during the first 30 calendar days from receipt, provided that the product remains in perfect condition for use.
Custom-made products and cut-to-size strips are excluded.
Full conditions here: After-sales service.
24h Free Delivery
If you place your order today before 2:30 pm, delivery within 24/48h (working days).
Shipping is free on purchases over £ 49.99 (incl. VAT).
Full conditions here: Delivery methods.
100% secure payments
At Ledkia we strive to protect your security and privacy. We use payment methods that guarantee your security. Both your personal and bank details are protected with all the security measures established in the current legislation.
More information: Payment methods.
Up to 5 year warranty
Our warranty service of up to 5 years guarantees the replacement, repair or refund of defective products.
You will find the exact product warranty in the technical details.
Full conditions here: After-sales service.
See alternatives
Dimensions
- Height152 mm
- Width152 mm
Downloads
Technical Data Sheet PDF
Certificates and Stamps
Technical Specifications
Technical Information
- CertificatesRoHS, CE, UKCAQuality, safety and compliance certifications that the product has obtained, such as CE, RoHS or UL, which guarantees that it meets industry standards and current regulations.
- ColourBlackSpecification of the color of the product or its light (in the case of products such as lamps or light bulbs), which may affect the aesthetics and functionality of its use.
- Current Intensity16 AAmount of electrical current that flows through the product, measured in amperes (A). It is key to ensuring safe and efficient operation.
- IP RatingIP68The IP protection indicates the level of resistance of a product to dust and water. The higher the number, the more protected it is.
- LocationOutdoor, IndoorSpecification that describes the purpose or application of the product, such as lighting, air conditioning, or security, among others.
- Maximum Voltage450 VThe highest voltage that a product or component can withstand without damage. It is important to ensure that the system is within safe operating limits.
- Working Temperature-40 °C~+105 °CInternal temperature range in which the product can operate efficiently and safely. It is important to ensure its reliability under different usage conditions.
Product Data
- Warranty3 yearsPeriod during which the customer has the right to have their product repaired or replaced in the event of manufacturing defects or malfunctions under normal conditions of use. For more information, consult our After-sales page.
Description
The connector is ideal for splicing or connecting electrical wiring in areas where the conditions require a high degree of watertightness and resistance to dust, humidity and water.
It has internal terminals for the connection of 3 poles (Phase, Neutral and Earth), with admissible cable cross-sections ranging from 0.5 mm² to 2.5 mm².
This Connector allows a maximum current of 16 A and 450 V AC.
