Galan Square 24W Aluminium CCT Selectable SwitchDimm Slim LED Ceiling Light 280x280mm
Ref: 95572
(3)5 out of 5 stars
Colour Black
In Stock, delivery in 15-20 days
Buy now, pay later
Credit payment
Dimensions
- Weight1.2 kg
- Dimensions28 mm x 280 mm x 280 mm
Downloads
PDF Datasheet 95572_198706 EN
DoC_95572_198706
DoC_95572_198706
Certificates and Stamps
Technical Specifications
Electrical Features
- DimmableYes
- Electrical Insulation ClassII
- Frequency50-60 Hz
- Type Of Dimming10% - 50% - 100%, SwitchDimm
- Voltage Range220-240V ACVoltage level required for the product to function correctly.
- Wattage24 W
Mechanical Features
- Ambient Working Temperature-20 °C~+50 °CTemperature range in which the product can operate optimally, ensuring its performance without overheating or damage.
- IK ProtectionIK05Protection grade that the product offers against physical impacts. It is measured on a scale from IK00 to IK10, with IK10 being the highest level of resistance to impact and mechanical damage.
- InstallationSurface
- IP RatingIP20The IP protection indicates the level of resistance of a product to dust and water. The higher the number, the more protected it is.
- LocationIndoor
- ShapeSquare
LED Features
- Colour Temperature3000K - 6000KDefines the light tone, from warm white to cool white, measured in Kelvin (K).
- Hours40.000 hoursEstimated lifespan of the product before it loses performance. Based on optimal, non-continuous use, and measured in hours of operation under controlled conditions.
- Light ColourCCT
- Lumen2400 lm
- Luminous Efficiency100 lm/WRatio between light output (lumens) and energy consumed (watts). A high value indicates better efficiency, ideal for saving energy without compromising lighting.
Product Information
- CertificatesCE, RoHS, UKCA
- Guarantee3 years
Driver Information
- Driver Intensity290 mA
- Driver Tension54 V-72 VVoltage level that the driver uses to power the LEDs or electrical components of the product, ensuring their proper functioning.
Materials and Finishes
- ColourBlack
- Fitting MaterialAluminium
Description
The 24W Galan Aluminium CCT Selectable SwitchDimm Slim Square LED Surface Lamp 280x280 mm offers a soft, homogeneous and efficient illumination and has a modern and Nordic design.
Features of the 24W Galan Aluminium CCT Selectable SwitchDimm Slim Square LED Surface Lamp 280x280 mm
It adapts to all types of finishes and its installation in any type of ceiling, whether plaster, concrete or other types of surfaces, is really simple. The Galán Square LED ceiling light is recommended for new construction or renovation, replacing old spotlights. It is perfectly suitable for use in living rooms, offices, receptions, bedrooms, corridors, etc., although it is mainly used in homes.
Illuminate and decorate any space in a unique way with the 24W Galan CCT Selectable SwitchDimm Slim Square LED Surface Lamp 280x280 mm, by means of a switch, you can select between 3 Colour Temperatures of the Ceiling Light: Warm White 3000K, Neutral White 4000K and Cool White 6000K.
In addition, it integrates the SwitchDimm system, allowing 3 brightness level settings with a single switch. To change brightness levels simply switch on, off and on quickly until the desired mode is found. The SwitchDimm system is not compatible with dimmer switches.
What does CCT (correlated colour temperature) mean?
When a product is marked as CCT it means that we can change the colour temperature. CCT is defined in degrees Kelvin, according to the colour perception of a white LED to the human eye, we can differentiate between 3 types of colour; a warm light, a neutral light and a cool light, from 2700-3500K, 4000-4500K and 5000-6500K respectively. The CCT values do not indicate anything about the colour rendering capability of the LED.
*For safety reasons and to avoid damage to the LEDs, the product must be turned off before changing the colour temperature selector.
