Range Expert
  • 20 W
    Wattage 20 W
  • 220-240V AC
    Voltage Range 220-240V AC
  • 2000 lm
    Lumen 2000 lm
  • 72 mm
    Diameter 72 mm
Image of 20W Wild 3-Circuit Track LED Spotlight 0-10V Dimmable Selectable CCT Multi-Angle 15-60º
    Image of 20W Wild 3-Circuit Track LED Spotlight 0-10V Dimmable Selectable CCT Multi-Angle 15-60º
    Video of 20W Wild 3-Circuit Track LED Spotlight 0-10V Dimmable Selectable CCT Multi-Angle 15-60º
    Image of 20W Wild 3-Circuit Track LED Spotlight 0-10V Dimmable Selectable CCT Multi-Angle 15-60º
    Image of 20W Wild 3-Circuit Track LED Spotlight 0-10V Dimmable Selectable CCT Multi-Angle 15-60º
    Image of 20W Wild 3-Circuit Track LED Spotlight 0-10V Dimmable Selectable CCT Multi-Angle 15-60º
    Image of 20W Wild 3-Circuit Track LED Spotlight 0-10V Dimmable Selectable CCT Multi-Angle 15-60º
    Video of 20W Wild 3-Circuit Track LED Spotlight 0-10V Dimmable Selectable CCT Multi-Angle 15-60º
    Image of 20W Wild 3-Circuit Track LED Spotlight 0-10V Dimmable Selectable CCT Multi-Angle 15-60º
    Image of 20W Wild 3-Circuit Track LED Spotlight 0-10V Dimmable Selectable CCT Multi-Angle 15-60º
1 / 9
  • 20 W

    Wattage

    20 W

  • 220-240V AC

    Voltage Range

    220-240V AC

  • 2000 lm

    Lumen

    2000 lm

  • 72 mm

    Diameter

    72 mm

  • 0-10 V

    Type Of Dimming

    0-10 V

  • UGR <19

    Glare Factor

    UGR <19

  • IP20

    IP Rating

    IP20

  • 210 mm x Ø72 mm

    Dimensions

    210 mm x Ø72 mm

  • 210 mm

    Height

    210 mm

  • 100 lm/W

    Luminous Efficiency

    100 lm/W

  • 24º, 60º

    Beam Angle

    24º, 60º

  • Aluminium

    Fitting Material

    Aluminium

20W Wild 3-Circuit Track LED Spotlight 0-10V Dimmable Selectable CCT Multi-Angle 15-60º

Download technical datasheet

Ref. Ledkia: 104019

Colour Black

Before 68,99 €

-14% (You save 10,00 €)

58,99 €

VAT included
Energetic efficiency

In Stock, delivery in 15-20 days

PRO CLUB badge

Are you a lighting professional or a company?

  • Great discounts off PVP
  • Extended Warranty
  • Exclusive Services

Buy now, pay later

Credit payment

    • 30 calendar days to return

      You can renounce to this product during the first 30 calendar days from receipt, provided that the product remains in perfect condition for use.


      Custom-made products and cut-to-size strips are excluded.


      Full conditions here: After-Sales Service.

    • 5-7 days Delivery

      If you place your order today before 18:00h, delivery within 5-7 days (working days).


      Shipping is free on purchases over 49,99 € (incl. VAT).


      Full conditions here: Shipping methods.

    • 100% secure payments

      payment method image 1

      payment method image 2

      At Ledkia we strive to protect your security and privacy. We use payment methods that guarantee your security. Both your personal and bank details are protected with all the security measures established in the current legislation.


      More information: Payment methods.

    • Warranty up to 5 years

      Our warranty service of up to 5 years guarantees the replacement, repair or refund of defective products.


      You will find the exact product warranty in the technical details.


      Full conditions here: After-Sales Service.

Dimensions

  • Depth170 mm
  • Height210 mm
  • Diameter72 mm

Downloads

  • pdf file

    PDF Datasheet 104019_212704 IE

  • pdf file

    DoC_104019_212704

Certificates and Stamps

CertificateCertificateCertificate

Technical Specifications

  • Electrical Features

    • Electrical Insulation ClassI
    • Frequency50-60 Hz
    • Light SourceCOB
    • Type Of Dimming0-10 V
    • Voltage level required for the product to function correctly.
      Voltage Range220-240V AC
    • Wattage20 W

  • LED Features

    • Measures in degrees how light spreads from the source. A wide angle covers more area, while a narrow one is ideal for highlighting details.
      Beam Angle24º, 60º
    • Measures how accurately a light source displays colours compared to natural light. A high CRI (close to 100) ensures accurate colour rendering.
      Colour Rendering Index90
    • Defines the light tone, from warm white to cool white, measured in Kelvin (K).
      Colour Temperature2700K - 3200K - 4000K
    • Low-glare products offer more comfortable lighting, suitable for extended use.
      Glare FactorUGR <19
    • Estimated lifespan of the product before it loses performance. Based on optimal, non-continuous use, and measured in hours of operation under controlled conditions.
      Hours50.000 hours
    • Light ColourSelectable (Warm - Cool)
    • Lumen2000 lm
    • Ratio between light output (lumens) and energy consumed (watts). A high value indicates better efficiency, ideal for saving energy without compromising lighting.
      Luminous Efficiency100 lm/W
    • Technology that ensures stable, flicker-free light. It improves visual experience and reduces eye fatigue.
      No FlickerNo Flicker

  • Mechanical Features

    • Temperature range in which the product can operate optimally, ensuring its performance without overheating or damage.
      Ambient Working Temperature-20 °C~+50 °C
    • Ability to move or rotate the spotlight to direct the light as desired.
      DirectionalYes
    • InstallationTrack
    • The IP protection indicates the level of resistance of a product to dust and water. The higher the number, the more protected it is.
      IP RatingIP20
    • LocationIndoor
    • Type Of TrackThree Phase
    • Internal temperature range in which the product can operate efficiently and safely. It is important to ensure its reliability under different usage conditions.
      Working Temperature-20 °C~+40 °C

  • Product Information

    • CertificatesCE, RoHS, SAA
    • Guarantee3 years
    • Product SeriesWild

  • Materials and Finishes

    • ColourBlack
    • Fitting MaterialAluminium

Description

The 20W Wild 3-Circuit Track LED Spotlight is a versatile lighting solution featuring a 0-10V dimmable driver and selectable colour temperatures ranging from warm to cool. This track spotlight incorporates multi-angle beam control from 15º to 60º, delivering precise illumination with a luminous efficiency of 100 lm/W and a high colour rendering index of 90 for accurate colour fidelity.

General information about 20W Wild 3-Circuit Track LED Spotlight 0-10V Dimmable Selectable CCT Multi-Angle 15-60º

This track spotlight is built with an aluminium fitting that ensures robustness and lightweight handling. It operates on a three-phase track system compatible with standard installations. The product features a COB light source that provides a controlled light distribution with selectable beam angles from 15º to 60º, allowing tailored lighting for diverse environments. The integrated 0-10V dimming system enables smooth intensity adjustment. With a lifespan of 50.000 hours and an electrical insulation class I, it is designed for reliable operation in indoor settings. The spotlight meets CE, RoHS, and SAA certifications, ensuring compliance with European and international standards. It is directional, facilitating targeted lighting applications.

Use and applications

This track spotlight is designed to provide adaptable lighting solutions in indoor environments such as retail spaces and offices, where precise and high-quality illumination is essential. In retail, the high CRI of 90 enhances product visibility and colour accuracy, thanks to the selectable beam angles that adapt to different display needs. For office installations, the dimmable driver and UGR<19 rating contribute to visual comfort by controlling glare and enabling adjustable light levels.

Operating within a voltage range of 220-240V AC and an ambient temperature range from -20 °C to +50 °C, this spotlight suits professional commercial environments requiring stable and efficient lighting. Its compatibility with three-phase tracks and aluminium construction ensures easy installation and durability. This solution is ideal when control over directionality and light quality is a priority.

Key benefits

  • Precise light control thanks to selectable beam angles from 15º to 60º, enabling tailored illumination.
  • High colour fidelity with a CRI of 90, ensuring realistic and vibrant colour rendering in commercial spaces.
  • Energy-efficient performance with 100 lm/W luminous efficiency, supporting sustainable lighting projects.
  • Visual comfort provided by a UGR rating below 19, reducing glare in work and retail areas.
  • Long operational life of 50.000 hours, minimising maintenance needs in professional installations.
  • Flexible dimming with a 0-10V driver for smooth brightness adjustments according to ambient requirements.
  • Robust aluminium fitting that guarantees durability and ease of installation on three-phase track systems.

Highlighted specifications

Power: 20 W; Light output: 2.000 lm; Colour rendering index: 90; Beam angle: selectable 15º–60º; Dimming type: 0-10 V; Voltage: 220–240 V AC; Lifespan: 50.000 hours; Insulation class: I.

Installation and maintenance

The spotlight is designed for installation on three-phase track systems, ensuring compatibility with common commercial infrastructure. Installation follows the standard track mounting procedure, allowing directional adjustment once fixed. The aluminium construction facilitates handling and secure fitting. Maintenance is minimal due to the long lifespan of the COB light source and efficient driver technology. Disconnect the power supply before any intervention to ensure safety during installation or maintenance.


Specialized lighting distribution in Ireland. If you are looking to buy 20W Wild 3-Circuit Track LED Spotlight 0-10V Dimmable Selectable CCT Multi-Angle 15-60º with a professional warranty, it is a leading choice for durability and efficiency. Estimated shipping in 3 to 4 days (subject to stock availability). Quality certified by CE, RoHS, SAA for professional installations and projects. Check price and availability here.

Frequently asked questions

  • What type of dimming does this spotlight support? — It incorporates a 0-10 V dimming system for smooth intensity control.
  • Is this product suitable for outdoor use? — This spotlight is rated IP20 and is intended for indoor applications only.
  • Can the beam angle be adjusted after installation? — Yes, the beam angle is selectable between 15º and 60º to adapt to lighting needs.
  • What is the expected lifespan of the light source? — The COB module has an operational life of 50.000 hours.
  • Which track system is compatible with this spotlight? — It is designed for three-phase track installations.
