  • 40 W
    Wattage 40 W
  • 220-240V AC
    Voltage Range 220-240V AC
  • 6000 lm
    Lumen 6000 lm
  • 24
    Number of LEDs 24
Image of 40W LED Streetlight 1-10V Dimmable LUMILEDS PHILIPS Xitanium Villa
    Image of 40W LED Streetlight 1-10V Dimmable LUMILEDS PHILIPS Xitanium Villa
    Image of 40W LED Streetlight 1-10V Dimmable LUMILEDS PHILIPS Xitanium Villa
    Image of 40W LED Streetlight 1-10V Dimmable LUMILEDS PHILIPS Xitanium Villa
    Image of 40W LED Streetlight 1-10V Dimmable LUMILEDS PHILIPS Xitanium Villa
    Image of 40W LED Streetlight 1-10V Dimmable LUMILEDS PHILIPS Xitanium Villa
    Image of 40W LED Streetlight 1-10V Dimmable LUMILEDS PHILIPS Xitanium Villa
    Image of 40W LED Streetlight 1-10V Dimmable LUMILEDS PHILIPS Xitanium Villa
    Image of 40W LED Streetlight 1-10V Dimmable LUMILEDS PHILIPS Xitanium Villa
    Image of 40W LED Streetlight 1-10V Dimmable LUMILEDS PHILIPS Xitanium Villa
    Image of 40W LED Streetlight 1-10V Dimmable LUMILEDS PHILIPS Xitanium Villa
    Image of 40W LED Streetlight 1-10V Dimmable LUMILEDS PHILIPS Xitanium Villa
1 / 11
  • 40 W

    Wattage

    40 W

  • 220-240V AC

    Voltage Range

    220-240V AC

  • 6000 lm

    Lumen

    6000 lm

  • 24

    Number of LEDs

    24

  • 1-10 V

    Type Of Dimming

    1-10 V

  • 0.95

    Power Factor

    0.95

  • IP66

    IP Rating

    IP66

  • No

    Battery Operated

    No

  • 766 mm

    Width

    766 mm

  • 440 mm

    Height

    440 mm

  • IK09

    IK Protection

    IK09

  • 150 lm/W

    Luminous Efficiency

    150 lm/W

40W LED Streetlight 1-10V Dimmable LUMILEDS PHILIPS Xitanium Villa

Download technical datasheet

Ref. Ledkia: 70510

Colour Temperature Candlelight 2200K

Optic Asymmetrical 140ºx60º

  • Available in other selections.

In Stock, delivery in 16-21 days

Before 314,99 €

-31% (You save 98,00 €)

216,99 €

VAT included
Energetic efficiency

In Stock, delivery in 16-21 days

PRO CLUB badge

Are you a lighting professional or a company?

  • Great discounts off PVP
  • Extended Warranty
  • Exclusive Services

Buy now, pay later

Credit payment

    • 30 calendar days to return

      You can renounce to this product during the first 30 calendar days from receipt, provided that the product remains in perfect condition for use.


      Custom-made products and cut-to-size strips are excluded.


      Full conditions here: After-Sales Service.

    • 5-7 days Delivery

      If you place your order today before 18:00h, delivery within 5-7 days (working days).


      Shipping is free on purchases over 49,99 € (incl. VAT).


      Full conditions here: Shipping methods.

    • 100% secure payments

      payment method image 1

      payment method image 2

      At Ledkia we strive to protect your security and privacy. We use payment methods that guarantee your security. Both your personal and bank details are protected with all the security measures established in the current legislation.


      More information: Payment methods.

    • Warranty up to 5 years

      Our warranty service of up to 5 years guarantees the replacement, repair or refund of defective products.


      You will find the exact product warranty in the technical details.


      Full conditions here: After-Sales Service.

Dimensions

  • Weight10.2 kg
  • Height440 mm
  • Width766 mm
  • Fixing DiameterØ76 mm
Scheme image

Downloads

  • pdf file

    Technical Data Sheet PDF

  • pdf file

    DoC_70510_213236

Certificates and Stamps

CertificateCertificateCertificate

Technical Specifications

  • Electrical Features

    • Electrical Insulation ClassI
    • Frequency50-60 Hz
    • Light SourceLUMILEDS SMD5050
    • Minimum and maximum voltage fluctuation that the product can withstand momentarily.
      Nominal Voltage100 V - 240 V
    • Product's ability to withstand voltage spikes or electrical overloads, protecting internal components from potential damage due to current fluctuations.
      Overvoltage Protection6 kV
    • Type Of Dimming1-10 V
    • Voltage level required for the product to function correctly.
      Voltage Range220-240V AC
    • Wattage40 W

  • LED Features

    • Defines the light tone, from warm white to cool white, measured in Kelvin (K).
      Colour Temperature2200K
    • Estimated lifespan of the product before it loses performance. Based on optimal, non-continuous use, and measured in hours of operation under controlled conditions.
      Hours100.000 hours
    • Efficiency of the LEDs, measured as the amount of light generated per unit of energy consumed (lumens per watt). High efficiency ensures energy savings without losing light quality.
      LED Performance160 lm/W
    • Light ColourCandlelight
    • Lumen6000 lm
    • Ratio between light output (lumens) and energy consumed (watts). A high value indicates better efficiency, ideal for saving energy without compromising lighting.
      Luminous Efficiency150 lm/W
    • Number of LEDs24
    • Power Factor0.95
    • Percentage of light emitted upwards by the product when installed. A low ULOR reduces light pollution.
      UlorLess than 0.1%

  • Mechanical Features

    • Temperature range in which the product can operate optimally, ensuring its performance without overheating or damage.
      Ambient Working Temperature-20 °C~+45 °C
    • Protection grade that the product offers against physical impacts. It is measured on a scale from IK00 to IK10, with IK10 being the highest level of resistance to impact and mechanical damage.
      IK ProtectionIK09
    • The IP protection indicates the level of resistance of a product to dust and water. The higher the number, the more protected it is.
      IP RatingIP66
    • LocationOutdoor
    • Type of lens that determines the distribution and quality of the light. It influences the illumination angle and light efficiency.
      OpticAsymmetrical 140ºx60º

  • Materials and Finishes

    • ColourBlack
    • Fitting MaterialAluminium, Glass

  • Product Information

    • CertificatesCE, RoHS, ENEC
    • Guarantee5 years

  • Driver Information

    • Driver BrandPHILIPS Xitanium
    • WifiNo

Description

The Villa LED Luminaire LUMILEDS 40W PHILIPS Xitanium Dimmable 1-10V Street Lighting is one of the latest-generation luminaires, offering instant start-up thanks to its LED technology, as well as high power. It is the ideal replacement for old discharge streetlights, improving light quality and significantly reducing energy consumption.

Features of the Villa LED 40W PHILIPS Xitanium Dimmable 1-10V Street Lighting

It incorporates the LUXEON 5050 2D light source. The light source is protected with tempered glass featuring an IP66 protection rating that makes it weather-resistant. Lumileds technology guarantees high luminous performance with extreme durability. Lumileds is a company dedicated to the development, manufacture and distribution of lighting and also holds more than 200 patents related to LED technology.

The luminaire body has been manufactured using an injection process to ensure optimal heatsink quality, in high-grade aluminium. It features an internal hinge that improves its aesthetics without losing versatility. A chemical and mechanical anti-corrosion treatment has been applied, UV-resistant to further enhance its aesthetic durability. In addition, for greater safety the luminaire includes surge protection.

Features of the XITANIUM 1-10V Dimmable Driver

An LED driver converts the AC mains into DC suitable to power LED chips. The Xitanium Driver it incorporates is from the prestigious PHILIPS company, one of the most innovative and renowned brands in the lighting industry; this driver is designed especially for Street Lighting. This range of drivers offers unique reliability and flexibility, delivering high performance and optimal efficiency for LEDs. The entire Xitanium driver range features an IP65 housing that protects against moisture, vibrations and temperature, ensuring maximum durability. It also includes both over-temperature and surge protection.

There are two types of mounting for this Villa LUMILEDS 40W PHILIPS Xitanium 1-10V Dimmable LED Luminaire. The mounting to the luminaire’s bracket is for a 27 mm diameter.

This version can dim the luminaire via 1-10V control, meaning the voltage of an analogue control circuit is adjusted to regulate the light intensity of the luminaire.

Reducing energy consumption represents significant savings for any urban area. Enjoy the best road lighting with the different options of our Villa Luminaire at your online store efectoLED.

* The luminaire colour code is RAL 9011.

* To install the Villa LED Luminaire on some columns, the ‘Villa LED Column Mount Bracket’ is required (see accessories).

*The customer's visual perception of sizes, colours, textures, and so on, of our products, can be affected by factors such as ambient lighting, screen calibration, viewing angle or the device of each user. The customer must bear in mind that any returns made for reasons not related to the functionality of the product will be at the customer's expense.
