  • 24V DC
    Voltage Range 24V DC
  • DALI
    Type Of Dimming DALI
  • IP20
    IP Rating IP20
  • No
    Battery Operated No
Image of DALI Master DT6 Monochrome 4-Zone Touch Screen SKYDANCE TD1-4S
    Image of DALI Master DT6 Monochrome 4-Zone Touch Screen SKYDANCE TD1-4S
    Image of DALI Master DT6 Monochrome 4-Zone Touch Screen SKYDANCE TD1-4S
    Image of DALI Master DT6 Monochrome 4-Zone Touch Screen SKYDANCE TD1-4S
    Image of DALI Master DT6 Monochrome 4-Zone Touch Screen SKYDANCE TD1-4S
1 / 4
  • 24V DC

    Voltage Range

    24V DC

  • DALI

    Type Of Dimming

    DALI

  • IP20

    IP Rating

    IP20

  • No

    Battery Operated

    No

  • 50 mm x 112 mm x 112 mm

    Dimensions

    50 mm x 112 mm x 112 mm

  • 112 mm

    Width

    112 mm

  • 50 mm

    Height

    50 mm

  • Glass

    Fitting Material

    Glass

  • SKYDANCE

    Brand

    SKYDANCE

  • Yes

    Dimmable

    Yes

  • -20 °C~+55 °C

    Working Temperature

    -20 °C~+55 °C

Skydance

DALI Master DT6 Monochrome 4-Zone Touch Screen SKYDANCE TD1-4S

Skydance
Download technical datasheet

Ref. Ledkia: 115057

Manuf. ref.: CR-DLTD1-4SW

Light Colour Monochrome

27,89 €

VAT included

In Stock, delivery in 15-20 days

PRO CLUB badge

Are you a lighting professional or a company?

  • Great discounts off PVP
  • Extended Warranty
  • Exclusive Services

Buy now, pay later

Credit payment

    • 30 calendar days to return

      You can renounce to this product during the first 30 calendar days from receipt, provided that the product remains in perfect condition for use.


      Custom-made products and cut-to-size strips are excluded.


      Full conditions here: After-Sales Service.

    • 5-7 days Delivery

      If you place your order today before 18:00h, delivery within 5-7 days (working days).


      Shipping is free on purchases over 49,99 € (incl. VAT).


      Full conditions here: Shipping methods.

    • 100% secure payments

      payment method image 1

      payment method image 2

      At Ledkia we strive to protect your security and privacy. We use payment methods that guarantee your security. Both your personal and bank details are protected with all the security measures established in the current legislation.


      More information: Payment methods.

    • Warranty up to 5 years

      Our warranty service of up to 5 years guarantees the replacement, repair or refund of defective products.


      You will find the exact product warranty in the technical details.


      Full conditions here: After-Sales Service.

Dimensions

  • Depth112 mm
  • Width112 mm
  • Height50 mm

Downloads

  • pdf file

    Technical Data Sheet PDF

  • pdf file

    Instruction Manual

  • pdf file

    DoC_115057_235317

Certificates and Stamps

CertificateCertificateCertificateCertificateCertificate

Technical Specifications

  • Mechanical Features

    • Temperature range in which the product can operate optimally, ensuring its performance without overheating or damage.
      Ambient Working Temperature-30 °C~+65 °C
    • The IP protection indicates the level of resistance of a product to dust and water. The higher the number, the more protected it is.
      IP RatingIP20
    • LocationIndoor
    • Internal temperature range in which the product can operate efficiently and safely. It is important to ensure its reliability under different usage conditions.
      Working Temperature-20 °C~+55 °C

  • Electrical Features

    • Type Of DimmingDALI
    • Voltage level required for the product to function correctly.
      Voltage Range24V DC

  • Product Information

    • BrandSKYDANCE
    • CertificatesCE, RoHS, EMC, RED, DALI 2
    • Guarantee5 years

  • Materials and Finishes

    • Fitting MaterialGlass

  • Driver Information

    • WifiNo

  • LED Features

    • Light ColourMonochrome

Description

The 4 Zone Tactile Wall Mounted DALI Master Dimmer is a touch controller that acts as a DALI master to control four DALI directions. It uses proximity detection technology to provide intuitive and effective control. Its elegant design integrates perfectly into professional DALI lighting systems.

Features of the 4 Zone Tactile Wall Mounted DALI Master Dimmer

Complies with the latest DALI standard protocol IEC62386 and is compatible with DALI products from other international additions. This touch panel is powered through the DALI bus 16VDC or a 24VDC source, making it versatile and easy to integrate into different installations.

This DALI Master offers control over lighting in four different zones. This means it can handle and adjust lighting in four separate areas independently, allowing for extreme customisation of the environment according to specific needs or events. Each zone can be configured with different colours, intensities, and effects, providing flexibility and creativity in lighting design. This level of zoned control is ideal for spaces that require multiple lighting environments or to enhance unique architectural features in each area.

A standout feature of this panel is its ability to select the DALI direction through an encoding switch. It also allows complete customisation of lighting control, including scenes, groups, and linking or fading modes. The touch panel is designed with an ultra-sensitive high-resistance glass surface that is not only elegant but also durable. Each button is equipped with a blue LED indicator, making it easy to identify the buttons in low-light conditions.
