220-240V LIFUD LED Driver 30-40V Output 135mA DC 6W LF-008S0135H

This constant current LED driver operates at an input voltage of 220-240 V AC and delivers a steady output of 135 mA DC with a power rating of 6 W. It features a compact design with IP20 protection, making it suitable for indoor electrical installations that require reliable current regulation.

General information about 220-240V LIFUD LED Driver 30-40V Output 135mA DC 6W LF-008S0135H

The 220-240V LIFUD LED Driver LF-008S0135H is a constant current (CC) driver designed to convert and stabilise electrical input into a consistent DC output suitable for LED applications. It functions within a nominal voltage range of 198 V to 264 V and provides a controlled current of 135 mA at an output voltage between 30 V and 40 V. The driver incorporates a robust plastic (PC) housing that ensures electrical safety and durability in indoor environments. Its IP20 rating indicates protection against solid objects larger than 12 mm, suitable for installation in electrical cabinets and technical enclosures. Certified under standards such as CB, CE, RoHS, ENEC, UKCA, CCC, and RCM, it meets rigorous safety and quality requirements. The device supports efficient power conversion at 6 W and operates reliably within an ambient temperature range of -20 °C to +45 °C.

Use and applications

This LED driver is designed to provide stable current regulation in indoor electrical installations, particularly in electrical cabinets where precise power supply control is essential. It suits sectors requiring dependable energy management, such as industrial and commercial facilities, benefiting from its consistent output current of 135 mA that ensures system stability. The driver’s plastic enclosure and IP20 protection make it appropriate for controlled environments where dust ingress is minimal.

Operating within a wide ambient temperature range of -20 °C to +45 °C, it adapts to varied indoor conditions without compromising performance. Its compact design facilitates integration into existing electrical systems, while compliance with multiple certifications guarantees safety and reliability. This solution is oriented to installations where maintaining a constant current and protecting the electrical system are critical, ensuring efficient and secure operation.

Key benefits

• Ensures stable LED current supply thanks to constant current regulation.
• Facilitates safe installation in indoor environments through its IP20 protection.
• Supports reliable operation within a wide ambient temperature range.
• Meets high safety standards with multiple certifications including CE and RoHS.
• Simplifies integration in technical enclosures due to its compact plastic housing.

Highlighted specifications

Input voltage: 220-240 V AC; Output current: 135 mA DC; Power: 6 W; Ambient temperature range: -20 °C to +45 °C; Protection rating: IP20.

Installation and maintenance

Installation must follow the specified mounting system for electrical drivers and ensure proper connection to the power source within the voltage range of 198 V to 264 V. The device should be positioned in an indoor environment free from excessive moisture or dust to maintain its IP20 protection. Routine inspections are recommended to verify electrical connections and the integrity of the plastic enclosure. Disconnect the power supply before any intervention.

Specialized lighting distribution in Ireland. If you are looking to buy 220-240V LIFUD LED Driver 30-40V Output 135mA DC 6W LF-008S0135H with a professional warranty, it is a leading choice for durability and efficiency. Estimated shipping in 3 to 4 days (subject to stock availability). Quality certified by CB, CE, RoHS, ENEC, UKCA, CCC, RCM for professional installations and projects. Check price and availability here.
