Wattage 800 W
Voltage Range 220-240V AC
Lumen 120000 lm
Type Of Dimming 0-10 V
Wattage
800 W
Voltage Range
220-240V AC
Lumen
120000 lm
Type Of Dimming
0-10 V
Power Factor
0.98
IP Rating
IP66
Battery Operated
No
Dimensions
600 mm x 188 mm x 353 mm
Width
188 mm
Height
600 mm
IK Protection
IK08
Luminous Efficiency
150 lm/W
LIFUD 0-10V Dimmable 800W Stadium LED Floodlight 160lm/W IP66
Ref. Ledkia: 110486
Colour Temperature Daylight 5000K
Optic 60º
In Stock, delivery in 16-21 days
Premium range
877,99 €Before 676,99 €
620,99 €
VAT included
In Stock, delivery in 16-21 days
Modular Product (Requires Assembly)
Are you a lighting professional or a company?
- Great discounts off PVP
- Extended Warranty
- Exclusive Services
Buy now, pay later
Credit payment30 calendar days to return
You can renounce to this product during the first 30 calendar days from receipt, provided that the product remains in perfect condition for use.
Custom-made products and cut-to-size strips are excluded.
Full conditions here: After-Sales Service.
5-7 days Delivery
If you place your order today before 18:00h, delivery within 5-7 days (working days).
Shipping is free on purchases over 49,99 € (incl. VAT).
Full conditions here: Shipping methods.
100% secure payments
At Ledkia we strive to protect your security and privacy. We use payment methods that guarantee your security. Both your personal and bank details are protected with all the security measures established in the current legislation.
More information: Payment methods.
Warranty up to 5 years
Our warranty service of up to 5 years guarantees the replacement, repair or refund of defective products.
You will find the exact product warranty in the technical details.
Full conditions here: After-Sales Service.
Dimensions
- Weight10.75 kg
- Cable Length60 mm
- Dimensions600 mm x 188 mm x 353 mm
Downloads
PDF Datasheet 110486_225255 IE
Stadium LIFUD Installation Manual
DoC_110486_225255
Certificates and Stamps
Technical Specifications
LED Features
- Colour Rendering Index70Measures how accurately a light source displays colours compared to natural light. A high CRI (close to 100) ensures accurate colour rendering.
- Colour Temperature5000KDefines the light tone, from warm white to cool white, measured in Kelvin (K).
- Hours60.000 hoursEstimated lifespan of the product before it loses performance. Based on optimal, non-continuous use, and measured in hours of operation under controlled conditions.
- LED Performance160 lm/WEfficiency of the LEDs, measured as the amount of light generated per unit of energy consumed (lumens per watt). High efficiency ensures energy savings without losing light quality.
- Light ColourDaylight
- Lumen120000 lm
- Luminous Efficiency150 lm/WRatio between light output (lumens) and energy consumed (watts). A high value indicates better efficiency, ideal for saving energy without compromising lighting.
- Number of switch-on cycles25000
- Power Factor0.98
- Standard colour deviation (MacAdam)SDCM ≤ 5
Electrical Features
- DimmableYes
- Electrical Insulation ClassI
- Frequency50-60 Hz
- Light SourceSMD5050
- Overvoltage Protection6 kVProduct's ability to withstand voltage spikes or electrical overloads, protecting internal components from potential damage due to current fluctuations.
- Type Of Dimming0-10 V
- Voltage Range220-240V ACVoltage level required for the product to function correctly.
- Wattage800 W
Mechanical Features
- Ambient Working Temperature-20 °C~+50 °CTemperature range in which the product can operate optimally, ensuring its performance without overheating or damage.
- IK ProtectionIK08Protection grade that the product offers against physical impacts. It is measured on a scale from IK00 to IK10, with IK10 being the highest level of resistance to impact and mechanical damage.
- InstallationSurface
- Installation of the bracketWall with U-bracket, On-wall base with U-bracket, Ceiling with U-bracket
- IP RatingIP66The IP protection indicates the level of resistance of a product to dust and water. The higher the number, the more protected it is.
- LocationOutdoor, Indoor
- Modular Product (Requires Assembly)Yes
- Optic60ºType of lens that determines the distribution and quality of the light. It influences the illumination angle and light efficiency.
- Special Installation EnvironmentHigh ambient temperature
- Working Temperature-20 °C~+45 °CInternal temperature range in which the product can operate efficiently and safely. It is important to ensure its reliability under different usage conditions.
Product Information
- CertificatesCE, RoHS, UKCA
- Guarantee3 years
- Product SeriesStadium PRO-I
Materials and Finishes
- ColourBlack
- Fitting MaterialPC, Aluminium
Driver Information
- Driver BrandLIFUD
- Driver Intensity0.9 A
- Driver Power180 W
- Driver Tension90 V - 305 VVoltage level that the driver uses to power the LEDs or electrical components of the product, ensuring their proper functioning.
- WifiNo
Description
The LIFUD 0-10V Dimmable 800W Stadium LED Floodlight is designed for professional lighting applications, featuring a high power output and IP66 protection for outdoor and indoor use.
General information about LIFUD 0-10V Dimmable 800W Stadium LED Floodlight 160lm/W IP66
This stadium floodlight belongs to the Stadium Profesional series, offering a modular design with a power of 800 W and a luminous efficiency of 150 lm/W. It includes a LIFUD driver with 0–10 V dimming capability and supports a voltage range of 220-240 V AC. The product features an IK08 impact protection and a degree of protection IP66, making it suitable for demanding environments. Its body is made of aluminium and polycarbonate components, and it has a colour rendering index (CRI) of 70. Dimensions are 600 mm x 188 mm x 353 mm.
Use and applications
This floodlight is intended for outdoor and indoor installations and is suitable for industry and production sectors. It is ideal for lighting access points, façades, and perimeter walls or fencing, providing effective illumination in various technical and professional environments.
Key benefits
- High luminous output: Provides 120,000 lumens to ensure powerful illumination for large areas.
- 0–10 V dimming: Allows precise adjustment of lighting levels through the integrated dimming system.
- Robust protection: Rated IP66 and IK08, suitable for harsh environments and resistant to impacts and dust.
- Modular design: Facilitates flexible installation and maintenance by enabling assembly and component replacement.
- Wide voltage range: Operates between 220-240 V AC with a driver supporting 90 V to 305 V, ensuring compatibility with various electrical systems.
Highlighted specifications
Power: 800 W; Ambient working temperature: -20 °C to +50 °C; Overvoltage protection: 6 kV; Electrical insulation class: I.
Installation and maintenance
Installation is surface-mounted with options for wall, on-wall base, or ceiling mounting using a U-bracket. The product requires assembly by the customer due to its modular nature. Disconnect the power supply before any intervention. Refer to the installation manual for detailed instructions and handling precautions.
Frequently asked questions
- What type of dimming does this floodlight support? — It supports 0–10 V dimming for lighting level adjustment.
- Is the floodlight suitable for outdoor installation? — Yes, it has an IP66 rating for outdoor use.
- What is the lifespan of the product? — It has a rated life of 60,000 hours.
- Which driver brand is used in this floodlight? — The LIFUD driver is integrated.
- What mounting options are available? — It can be installed on walls, ceilings, or on-wall bases using a U-bracket.
Specialised technical lighting distribution in Ireland. If you are looking to buy LIFUD 0-10V Dimmable 800W Stadium LED Floodlight 160lm/W IP66 for a technical or professional project, the Stadium Profesional series identifies the range to which this reference belongs. Estimated shipping time of 3 to 4 days (subject to stock availability). Between the product data, CE, RoHS, and UKCA certifications are indicated as applicable. Check price and availability.
This product requires assembly by the customer. For correct handling and installation, please refer to the installation manual.
