Egina
Egina Silent Ceiling Fan with DC Motor in Black 132cm
77,99 €
145,99 €
Ref: 117603
|Manuf. ref.: KTVT-LGBL-132DCL
Wifi No
Configuration With light
Switch Type Remote
Producto no disponible
Buy now, pay later
Credit paymentVideos
How to Install a FanInstallation
How to Synchronize a Fan with “Tuya Smart”Tutorial
How to Synchronize Two Fans with the Same Remote ControlTutorial
Dimensions
- Dimensions420 mm x Ø1360 mm
- Weight6.7 kg
- Mounting Plate Dimensions60 mm x Ø155 mm
Downloads
Technical Data Sheet PDF
DoC_117603_246236
Certificates and Stamps
Technical Specifications
Electrical Features
- ConfigurationWith light
- DimmableYes
- Electrical Insulation ClassI
- Fan Wattage45 W
- Frequency50-60 Hz
- Number Of Speeds6
- Remote ControlYes
- Sound level range24 dB - 42 dB
- Speed Range113 RPM - 212 RPM
- Summer/Winter ModeYesFunction that reverses the fan's rotation to optimize air circulation according to the season. In summer, it helps to cool, and in winter, it distributes heat more efficiently.
- Switch TypeRemote
- Type Of DimmingRemote Control
- Type Of MotorDC
- Voltage Range220-240V ACVoltage level required for the product to function correctly.
Mechanical Features
- Ambient Working Temperature-20 °C~+50 °CTemperature range in which the product can operate optimally, ensuring its performance without overheating or damage.
- InstallationSurface
- IP RatingIP20The IP protection indicates the level of resistance of a product to dust and water. The higher the number, the more protected it is.
- LocationIndoor
- Recommended AreaLarge (between 20–30 m²)
Product Information
- BrandTECHBREY
- CertificatesCE, RoHS, UKCA
- Guarantee3 years
- Product SeriesEgina
Materials and Finishes
- Blade ColourBlack
- ColourBlack
- Fitting MaterialMetal, ABS Plastic
LED Features
- Hours40.000 hoursEstimated lifespan of the product before it loses performance. Based on optimal, non-continuous use, and measured in hours of operation under controlled conditions.
- Luminous power18 W
Driver Information
- ConnectivityRF
- WifiNo
Description
The Egina Silent Ceiling Fan with DC Motor in Black 132cm with 38W incorporates a light source with LED technology and CCT of 18W power. Presenting a classic and elegant look that makes it a decorative and functional element.
The fan incorporates a DC motor that stands out for its lightness, durability, efficiency, and low energy consumption. Some of the advantages of a fan with a DC motor compared to a fan with an AC motor are:
- Extremely silent fan and without wobbles. Thanks to its DC motor, we manage to reduce the sound emitted by the fan, up to 50% compared to AC motors, making the fan perfect for rest, study, and work areas.
- Low consumption. Fans with DC motors consume up to 70% less energy compared to AC motors, resulting in savings on our home electricity bill.
- They are quicker to start, change speed, and stop. Additionally, it includes 6 speed modes compared to the 3 or 4 speeds of AC motors.
It has a remote control with 6 functions:
- On and off
- Selection of colour temperature (Warm-Neutral-Cool)
- Light adjustment
- 6 speeds
- Timer 1/2/4 hours
- Summer/Winter function
Through Air Dual technology or Reverse System, the fan is equipped with 2 operating modes (summer/winter). With this system, the direction of the motor rotation and the blades is reversed, dissipating hot air in summer and evenly distributing the heat from the heating system in winter, improving the thermal sensation, optimising the heating system's operation, and contributing to energy savings.
It integrates CCT LED light, allowing us to change the colour temperature between 3 types of light (warm light, cool light, and neutral light) and create different ambiences according to needs.
To synchronise the driver with the remote, connect the fan to the power supply and press the ON/OFF button on the remote control for 8 seconds.The Silent Egina Ceiling Fan is a perfect way to keep your home's rooms cool and illuminated without having to install an air conditioner.
* The maximum distance of the fan from the ceiling is 48 cm.
* This fan is capable of conditioning an area larger than 20 m².
What does CCT (correlated colour temperature) mean?
When a product is marked as CCT, it means we can change the colour temperature. CCT is defined in Kelvin degrees, according to the human eye's colour perception of a white LED, we can differentiate them into 3 types of colour; warm light, neutral light, and cool light, from 2700-3500K, 4000-4500K, and 5000-6500K respectively. CCT values do not indicate anything about the LED's colour rendering capability.
* Includes a spare long rod that allows you to extend your fan by 10cm
To activate the synchronisation mode of the WiFi fan controller, press and hold the ‘4h’ button for 8 seconds until you hear a double beep, then add it to the Tuya Smart Life app.
