Range Expert
  • 300 W
    Wattage 300 W
  • 220-240V AC
    Voltage Range 220-240V AC
  • 45000 lm
    Lumen 45000 lm
  • 408
    Number of LEDs 408
Image of Profesional Stadium 300W LED Floodlight 0-10V Dimmable LUMILEDS 170lm/W INVENTRONICS
    Image of Profesional Stadium 300W LED Floodlight 0-10V Dimmable LUMILEDS 170lm/W INVENTRONICS
    Image of Profesional Stadium 300W LED Floodlight 0-10V Dimmable LUMILEDS 170lm/W INVENTRONICS
1 / 2
  • 300 W

    Wattage

    300 W

  • 220-240V AC

    Voltage Range

    220-240V AC

  • 45000 lm

    Lumen

    45000 lm

  • 408

    Number of LEDs

    408

  • 0-10 V

    Type Of Dimming

    0-10 V

  • 0.95

    Power Factor

    0.95

  • IP66

    IP Rating

    IP66

  • No

    Battery Operated

    No

  • 140 mm x 297 mm x 484 mm

    Dimensions

    140 mm x 297 mm x 484 mm

  • 297 mm

    Width

    297 mm

  • 140 mm

    Height

    140 mm

  • IK10

    IK Protection

    IK10

Profesional Stadium 300W LED Floodlight 0-10V Dimmable LUMILEDS 170lm/W INVENTRONICS

Download technical datasheet

Ref. Ledkia: 181063

Colour Temperature Daylight 5000K

Optic 30º

Pre-Order, estimated shipping from 17/08/2026

New

268,99 €

VAT included

Pre-Order, estimated shipping from 17/08/2026

PRO CLUB badge

Are you a lighting professional or a company?

  • Great discounts off PVP
  • Extended Warranty
  • Exclusive Services

Buy now, pay later

Credit payment

    • 30 calendar days to return

      You can renounce to this product during the first 30 calendar days from receipt, provided that the product remains in perfect condition for use.


      Custom-made products and cut-to-size strips are excluded.


      Full conditions here: After-Sales Service.

    • 5-7 days Delivery

      If you place your order today before 18:00h, delivery within 5-7 days (working days).


      Shipping is free on purchases over 49,99 € (incl. VAT).


      Full conditions here: Shipping methods.

    • 100% secure payments

      payment method image 1

      payment method image 2

      At Ledkia we strive to protect your security and privacy. We use payment methods that guarantee your security. Both your personal and bank details are protected with all the security measures established in the current legislation.


      More information: Payment methods.

    • Warranty up to 5 years

      Our warranty service of up to 5 years guarantees the replacement, repair or refund of defective products.


      You will find the exact product warranty in the technical details.


      Full conditions here: After-Sales Service.

Dimensions

  • Height140 mm
  • Width297 mm
  • Depth484 mm
  • Weight6.5 kg
Scheme image

Downloads

  • pdf file

    PDF Datasheet 181063_366061 IE

  • pdf file

    G2StadiumUserManual_V12401_1_

  • pdf file

    DRIVER_INVENTRONICS_N2025_12_24

Certificates and Stamps

CertificateCertificateCertificate

Technical Specifications

  • Driver Information

    • Auxiliary Cable0-10V
    • Driver BrandINVENTRONICS
    • Driver Intensity1600 mA
    • Driver Power50 W-500 W
    • Voltage level that the driver uses to power the LEDs or electrical components of the product, ensuring their proper functioning.
      Driver Tension480 V
    • Selectable Wattage300 W - 200 W - 100 W
    • Type Of Driver0-10V
    • WifiNo

  • Electrical Features

    • Electrical Insulation ClassI
    • Frequency50-60 Hz
    • Light SourceLUMILEDS SMD2835
    • Minimum and maximum voltage fluctuation that the product can withstand momentarily.
      Nominal Voltage100 V - 277 V
    • Product's ability to withstand voltage spikes or electrical overloads, protecting internal components from potential damage due to current fluctuations.
      Overvoltage Protection10 kV
    • Type Of Dimming0-10 V
    • Voltage level required for the product to function correctly.
      Voltage Range220-240V AC
    • Wattage300 W

  • Materials and Finishes

    • ColourGrey
    • Fitting MaterialAluminium, Glass, PC
    • IncludesBracket, Quick Connector, Driver
    • RAL Colour9006

  • Mechanical Features

    • Temperature range in which the product can operate optimally, ensuring its performance without overheating or damage.
      Ambient Working Temperature-30 °C~+45 °C
    • Protection grade that the product offers against physical impacts. It is measured on a scale from IK00 to IK10, with IK10 being the highest level of resistance to impact and mechanical damage.
      IK ProtectionIK10
    • InstallationSurface
    • Installation of the bracketWall with U-bracket, Pole with U-bracket, On-wall base with U-bracket
    • The IP protection indicates the level of resistance of a product to dust and water. The higher the number, the more protected it is.
      IP RatingIP66
    • LocationOutdoor
    • Type of lens that determines the distribution and quality of the light. It influences the illumination angle and light efficiency.
      Optic30º
    • Rotation Angle0 ° - 90 °

  • LED Features

    • Brightness range45000 lm - 30000 lm - 15000 lm
    • Measures how accurately a light source displays colours compared to natural light. A high CRI (close to 100) ensures accurate colour rendering.
      Colour Rendering Index80
    • Defines the light tone, from warm white to cool white, measured in Kelvin (K).
      Colour Temperature5000K
    • Estimated lifespan of the product before it loses performance. Based on optimal, non-continuous use, and measured in hours of operation under controlled conditions.
      Hours80.000 Horas
    • Efficiency of the LEDs, measured as the amount of light generated per unit of energy consumed (lumens per watt). High efficiency ensures energy savings without losing light quality.
      LED Performance170 lm/W
    • Light ColourDaylight
    • Lumen45000 lm
    • Ratio between light output (lumens) and energy consumed (watts). A high value indicates better efficiency, ideal for saving energy without compromising lighting.
      Luminous Efficiency150 lm/W
    • Technology that ensures stable, flicker-free light. It improves visual experience and reduces eye fatigue.
      No FlickerNo Flicker
    • Number of LEDs408
    • Power Factor0.95
    • Standard colour deviation (MacAdam)SDCM ≤ 5

  • Product Information

    • CertificatesCE, RoHS, UKCA
    • Guarantee5 years
    • Product SeriesStadium PRO-I

Description

The Profesional Stadium 300W LED Floodlight is a high-performance projector floodlight designed for outdoor use, featuring a 300 W power capacity and a 0-10V dimmable driver from INVENTRONICS. It delivers a luminous efficiency of 150 lm/W and a total luminous flux of 45,000 lumens, ideal for professional lighting applications requiring precise control and robust performance.

General information about Profesional Stadium 300W LED Floodlight 0-10V Dimmable LUMILEDS 170lm/W INVENTRONICS

This projector floodlight incorporates a durable aluminium housing combined with glass and PC components, ensuring mechanical strength and weather resistance. It is rated IP66 for protection against dust and water jets, and IK10 for impact resistance, making it suitable for demanding external environments. The light source consists of LUMILEDS SMD2835 LEDs, offering a high colour rendering index (CRI) of 80 for accurate colour reproduction. The INVENTRONICS driver supports 0-10 V dimming control, allowing flexible adjustment of light intensity. With a ULOR of 0%, it minimises upward light spill, enhancing energy efficiency and reducing light pollution. The product series “Stadium Profesional” is known for modularity and options in optics and power, suitable for sports and large area lighting.

Use and applications

The Profesional Stadium 300W LED Floodlight is designed for outdoor installation in scenarios such as sports facilities or large open areas, where surface mounting is required. Its robust IP66 protection and IK10 resistance make it reliable for urban lighting projects managed by municipalities or sports venue operators, ensuring durability under variable weather and impact conditions. The floodlight’s 0-10 V dimmable driver allows integration into intelligent lighting control systems, providing adaptability for different lighting needs and energy management in professional sectors.

Operating within an ambient temperature range of -30 °C to +45 °C and a nominal voltage range of 220–240 V AC, it suits various geographic locations and electrical environments. The built-in overvoltage protection up to 10 kV adds security against electrical surges. This floodlight offers a long service life of 80,000 hours, reducing maintenance frequency. Its design ensures safe installation and operation, optimised for professional projects where control, reliability, and robustness are critical.

Key benefits

  • High luminous efficiency thanks to LUMILEDS SMD2835 LEDs, delivering bright and consistent illumination.
  • Durable construction with aluminium, glass, and PC materials ensures resistance to harsh outdoor conditions.
  • Advanced dimming capability via 0-10 V driver allows precise light control for energy management.
  • Excellent protection levels IP66 and IK10 provide security against dust, water, and impacts.
  • Zero upward light emission (ULOR 0%) minimises light pollution and enhances environmental compliance.

Highlighted specifications

Power: 300 W; Luminous flux: 45,000 lm; Protection rating: IP66; Impact resistance: IK10; Colour rendering index: 80; Power factor: 0,95.

Installation and maintenance

The floodlight is intended for surface mounting using the included bracket, compatible with wall, pole, or on-wall base installations with U-bracket options. Installation must respect the electrical insulation class I requirements and ensure correct connection to the 220–240 V AC supply. The product includes a driver and quick connector to facilitate wiring. Maintenance is simplified by the long operational lifespan and robust design, reducing the need for frequent interventions.

Disconnect the power supply before any intervention.


Specialized lighting distribution in Ireland. If you are looking to buy Profesional Stadium 300W LED Floodlight 0-10V Dimmable LUMILEDS 170lm/W INVENTRONICS with a professional warranty, it is a leading choice for durability and efficiency. Estimated shipping in 5 to 6 days (subject to stock availability). Quality certified by CE, RoHS, UKCA for professional installations and projects. Check price and availability here.
