Inversor Solar Híbrido GoodWe ES Cargador de Baterías con Inyección a Red 3.6-4.6 kW Monofásico

4.6-6.5 kW Single Phase GoodWe ES Hybrid Solar Inverter Battery Charger with Grid Injection

Ref: 96882 / GWXXXXD-ES

Before

Price not available

Would you like us to call you?
FREE

4.6-6.5 kW Single Phase GoodWe ES Hybrid Solar Inverter Battery Charger with Grid Injection

Ref: 96882 / GWXXXXD-ES

  • 4.6 kW-6.5 kW
  • IP65
  • 440x516x184 mm
  • 3 Years
  • 16kg // 20kg
  • VDE
  • Aluminium, PC
  • Indoor, Outdoor
  • -20ºC ~ +60ºC
  • I
  • 440 mm
  • 516 mm

Similar products

Description 4.6-6.5 kW Single Phase GoodWe ES Hybrid Solar Inverter Battery Charger with Grid Injection

The 4.6-6.5 kW Single Phase GoodWe ES Hybrid Solar Inverter Battery Charger with Grid Injection is an inverter that can charge batteries and can also be connected to the grid. They are the most interesting inverters because during the day they charge the battery with the surplus energy and can be used at night to be as self-sufficient as possible. At night the battery provides us with electrical energy and when the battery is about to run out, it would start consuming energy from the grid.

This type of inverter is specially designed to reduce the electricity bill as much as possible. Their price-performance ratio is extremely attractive and the return on investment is very interesting. It can charge all types of 48 Volt batteries such as PYLONTECH 48V batteries which are the most common and well known on the market. This inverter can work with or without batteries.

During the day, the surplus energy is used to charge the batteries, but once the battery is fully charged, the surplus energy is fed into the grid. The energy suppliers have surplus energy compensation systems in order to be able to sell the surplus energy. If you wish to block the surplus energy produced by the inverter you will need to purchase a monitoring and zero discharge kit which is sold separately. By blocking the surplus energy the inverter is no longer connected to the grid and commissioning would be much quicker as it would no longer require approval from the Ministry of Industry or Regulatory Body Inspection.

Features of the 4.6-6.5 kW Single Phase GoodWe ES Hybrid Solar Inverter Battery Charger with Grid Injection

The inverter has two MPPT inputs. The MPPT (Maximum Power Point Tracking) ensures that it finds the point where the solar panels generate the maximum power output. The MPPT works between 125 and 550V DC. It has a maximum charge and discharge current of 100A.

It can be connected via Wifi and RJ45 LAN cable, which is purchased separately. Thanks to the App for iOS and Android (PV Master) you can monitor the inverter at all times. If you wish to monitor both the solar production and the consumption of your home, you will need to purchase the Smart meter, which is sold separately. This inverter can be installed both indoors and outdoors thanks to its IP65 protection level.

Characteristics 4.6-6.5 kW Single Phase GoodWe ES Hybrid Solar Inverter Battery Charger with Grid Injection

Power: 4.6 kW-6.5 kW
MPPT Voltage Range: 125~550V DC
MPPT Maximum Intensity 11 A
Number of MPPT Trackers: 2
Max Output Current: 40 A
Max Shortciruit Current (A): 13.8 A
Protection Class: I
Use: Outdoor, Indoor
IP Protection: IP65
Material: Aluminium, PC
Size: 440x516x184 mm
Height: 440 mm
Width: 516 mm
Length: 184 mm
Total Weight: 16kg // 20kg
Working Temperature: -20ºC ~ +60ºC
Number of Batteries: 1
Battery Voltage: 48 V
Manual: Yes
Warranty: 3 Years
Certifications: TÜV, VDE, CE & RoHS
