Power:
3.6-6 kW
Voltage:
220-240V AC
Maximum Power:
5.4-9 kW
MPPT Voltage Range:
90-550V DC
MPPT Maximum Intensity
12.5 A
Number of MPPT Trackers:
2
Power Factor:
0.80
IP Protection:
IP65
Size:
470x470x190 mm
Width:
470 mm
Height:
470 mm
Connectivity:
Bluetooth, Wi-Fi
Single-Phase Hybrid Solar Inverter SAJ H1 48V Pylontech Battery Charger Grid Injection 3.6-6 kW
Ref. Ledkia: 86588
Ref. Fab: 060047
EAN 13 8445044059119
Choose Power (W)
3600 W
1674,62 €
23% VAT includedIn Stock, estimated delivery from 15-25 days
Are you a lighting professional or a company?
- Great discounts on RRP
- Extended warranty
- Exclusive services
Buy now, pay later
Credit payment30 Day Return
You can renounce to this product during the first 30 calendar days from receipt, provided that the product remains in perfect condition for use.
Custom-made products and cut-to-size strips are excluded.
Full conditions here: After-sales service.
5-7 days Free Delivery
If you place your order today before 18:00h, delivery within 5-7 days (working days).
Shipping is free on purchases over 49,99 € (incl. VAT).
Full conditions here: Delivery methods.
100% secure payments
At Ledkia we strive to protect your security and privacy. We use payment methods that guarantee your security. Both your personal and bank details are protected with all the security measures established in the current legislation.
More information: Payment methods.
Up to 5 year warranty
Our warranty service of up to 5 years guarantees the replacement, repair or refund of defective products.
You will find the exact product warranty in the technical details.
Full conditions here: After-sales service.
Don't forget the accessories 6
Multi-Contact MC4 1/1 IP68 Connectors for a 4-6mm² Cable
In Stock, delivery in 15-20 days
1 options1,82 €
Lithium Battery PYLONTECH 48V US2000C 2.4 kWh
In Stock, delivery in 15-20 days
1 options1332,66 €
PYLONTECH 48V Lithium Battery US3000C 3.6 kWh
In Stock, delivery in 15-20 days
1 options1627,45 €
Lithium Battery 48V SAJ B1 5.1 kWh
In Stock, estimated delivery from 3-5 weeks
1 options3183,96 €
SAJ SMART METER 24h Consumption Analyser Meter for zero discharge in Hybrid Inverters H1 and H2
In Stock, estimated delivery from 3-5 weeks
2 options117,91 €
PYLONTECH Lithium Battery 48V US5000C 4.8 kWh
In Stock, estimated delivery from 3-5 weeks
1 options2122,71 €
Dimensions
- Total Weight:23 kg
- Size:470x470x190 mm
- Height:470 mm
- Width:470 mm
- Length:190 mm
Downloads
Technical Data Sheet PDF
Manual SAJ H1-GB
Datasheet SAJ H1
Certificates SAJ H1
Certificates and Stamps
Technical Specifications
- Power:3.6-6 kW
- Maximum Power:5.4-9 kW
- Power Factor:0.80
- Voltage:220-240V AC
- MPPT Voltage Range:90-550V DC
- MPPT Maximum Intensity12.5 A
- Number of MPPT Trackers:2
- Frequency:50-60 Hz
- Protection Class:I
- Use:Indoor, Outdoor
- IP Protection:IP65
- Material:PC, Aluminium
- Installation:Surface
- Size:470x470x190 mm
- Height:470 mm
- Width:470 mm
- Length:190 mm
- Total Weight:23 kg
- Battery operated:Yes
- Number of Batteries:1
- Battery Voltage:48 V
- Wi-Fi:IEEE 802.11 / 2.4GHz
- Connectivity:Wi-Fi, Bluetooth
- Warranty:3 Years
- Certifications:CE & RoHS, UKCA
- Brand:SAJ
Our advantages
Team of experts at your service
Personal customer service
24-hour express delivery
Stock of more than 12,000 references
Warranty up to 5 years
Our professionals guarantee you the highest quality and reliability
Best price guarantee
Compared to the most outstanding websites in the industry
Description
The Single-Phase Hybrid Solar Inverter SAJ H1 48V Pylontech Battery Charger Grid Injection 3.6-6 kW is an inverter that can charge batteries and can also be connected to the mains. They are the most interesting inverters because during the day they charge the battery with the surplus energy. At night the battery provides light and when the battery runs out, it starts consuming from the mains. It has two MPPT inputs where two strings of panels can be connected. Using the ePortal platform and a WiFi connection, you can monitor production and consumption data or carry out remote maintenance.
This inverter can work with or without batteries. Its main function is to transform the direct current from the panels into alternating current and charge batteries. The inverter can charge a battery with the surplus of the photovoltaic production and in this way have energy available at night and be as self-sufficient as possible. The SAJ H1 hybrid range offers a very interesting entry-level range for the residential or small business environment. The price-performance ratio is extremely attractive and the return on investment is very interesting. It can charge 48V Pylontech batteries which are the most common and well known on the market.
Features of the Single-Phase Hybrid Solar Inverter SAJ H1 48V Pylontech Battery Charger Grid Injection 3.6-6 kW
It has 2 MPPT (Maximum power point tracking) regulators with a wide range of operating voltage that will allow us to make series of panels with greater comfort and flexibility. The MPPT work between 90 and 550VDC.
To get the inverter to reduce output power and avoid dumping excess production to the grid it will be necessary to purchase a compatible wattmeter (sold separately) or increase the storage capacity in 48V batteries. It has a very good connectivity thanks to the integrated Wifi and RS232 communication. It has an App for IOS and Android to monitor at all times. Its interface is simple and visual to be able to control its operation or any type of error.
H1 inverters can be installed indoors and outdoors thanks to their IP65 protection level and do not incorporate fans, so they are quieter than other inverters on the market.
