Round 18W LED Surface Panel SwitchCCT Selectable Ø 225mm
Price
Before £
£
Price not available
Ref: 6635 / CCT-PLFNR-18
This Round 18W LED Surface Panel SwitchCCT Selectable Ø 225mm stands out for its thin design which is perfect for when we don't have enogugh space above the ceiling to install larger lights. You can change its colour temperature from a cosy warm white to a relaxed cool white to adapt the room to the desired needs from the switch already installed.
Its SMD light source provides a light similar to that produced by a conventional ceiling light of about 120W, so the savings in electricity consumption that we obtain allow us to drastically reduce our lighting bill, maintenance costs and also on the replacement of luminaires. Highly resistant materials such as aluminium have been used in the manufacture of the 18W Round LED Surface Panel. This type of material facilitates the dissipation of the dissipation of the heat, improving the performance of the luminaire.
How to switch between different Colour Temperatures?
Integrates SwitchCCT System. Its operation is very simple, it allows 3 light colour settings with a single switch. To change the light colour you only have to turn on, turn off and turn on quickly until you find the desired mode. In addition, this system is equipped with memory which allows you to remember the last selected mode when the switch-off is normal. The SwitchCCT system is not compatible with dimmer switches.
What is CCT (Correlated Colour Temperature)?
When a product is marked as CCT it means that the colour temperature can be changed. CCT is defined in degrees Kelvin, according to the colour perception of a white LED to the human eye, we can differentiate them into 3 types of colour; warm white, daylight and cool white, which range from 2700-3500K, 4000-4500K and 5000-6500K. The CCT values do not indicate anything about the colour rendering ability of the LED.
Power: | 18 W |
Voltage: | 220-240V AC |
Multi-Voltage: | 85-265V AC |
Frequency: | 50-60 Hz |
Driver Output: | 45-75V DC // 250 mA |
Protection Class: | II |
Light Source: | OSRAM |
Light Colour: | CCT |
Colour Temp: | 2700K - 6000K |
Lumens: | 1620 lm |
Luminous Efficiency: | 90 lm/W |
Energy Efficiency 2021 (UE-1369/2017): | A+ |
Energy Efficiency 2023 (UE-2019/2015): | F |
Beam Angle: | 120º |
Lens Type: | Frost |
Use: | Indoor |
IP Protection: | IP20 |
Material: | Aluminium,PC |
Installation: | Surface |
Size: | 40xØ225 mm |
Height: | 40 mm |
Diameter: | Ø225 mm |
Total Weight: | 0.47 kg |
Frame: | White |
Working Temperature: | -20°C ~ +45°C |
Doesn't include: | Switch |
Life Span: | 40,000 Hours |
Warranty: | 3 Years |
Certifications: | CE & RoHS,UKCA |
